TE Connectivity 1532185-2 51 Way 1.27 mm Pitch Panel Mount D-Sub Connector
- RS Stock No.:
- 503-298
- Distrelec Article No.:
- 303-25-209
- Mfr. Part No.:
- 1532185-2
- Brand:
- TE Connectivity
Subtotal (1 unit)*
£419.95
(exc. VAT)
£503.94
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 13 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £419.95 |
*price indicative
- RS Stock No.:
- 503-298
- Distrelec Article No.:
- 303-25-209
- Mfr. Part No.:
- 1532185-2
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Number of Contacts | 51 | |
| Product Type | D-Sub Connector | |
| Current | 3A | |
| Mount Type | Panel Mount | |
| Connector Type D | D Connector | |
| Termination Type | Lead | |
| Minimum Operating Temperature | -55°C | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | EU RoHS Directive 2011/65/EU Compliant, EU REACH Regulation (EC) No. 1907/2006, EU ELV Directive 2000/53/EC Compliant, China RoHS 2 Directive MIIT Order No 32, 2016 | |
| Series | 1532185-2 | |
| Pitch | 1.27mm | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Number of Contacts 51 | ||
Product Type D-Sub Connector | ||
Current 3A | ||
Mount Type Panel Mount | ||
Connector Type D D Connector | ||
Termination Type Lead | ||
Minimum Operating Temperature -55°C | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals EU RoHS Directive 2011/65/EU Compliant, EU REACH Regulation (EC) No. 1907/2006, EU ELV Directive 2000/53/EC Compliant, China RoHS 2 Directive MIIT Order No 32, 2016 | ||
Series 1532185-2 | ||
Pitch 1.27mm | ||
- COO (Country of Origin):
- MX
The TE Connectivity plug and cable-to-board connector is designed to provide seamless connectivity in a compact form factor. Ideal for applications requiring high-density interconnections, this product features a microdot design that allows for efficient signal transmission, making it perfect for use in microminiature and nanominiature D connectors. The 51-position layout ensures that various electrical needs are met, while its panel mount capability provides versatility in installation. With a centreline pitch of just 1.27 mm, this connector is tailored for tight spaces, ensuring maximum performance without compromising on space. Engineered for robustness, it operates within a wide temperature range, making it suitable for diverse environmental conditions.
Microminiature design for space-efficient applications
Panel mount configuration for flexible installation options
51-position capacity supports a wide range of connections
Rated for up to 3 A, ensuring reliable current handling
Preterminated flying leads simplify the connection process
Low halogen content contributes to environmental compliance
Wave solder capable, allowing for versatile soldering processes
