TE Connectivity HD20 9 Way Vertical 2.74 mm Pitch Board D-Sub Connector, with Threaded Insert

View all D Sub Connectors

Subtotal (1 tube of 34 units)*

£177.42

(exc. VAT)

£212.90

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 13 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s)
Per Tube
Per unit*
1 +£177.42£5.218

*price indicative

D-Sub-Backshells
D Sub Backshells
Don't forget D Sub Backshells!
Shop D Sub Backshells now
RS Stock No.:
476-650
Distrelec Article No.:
304-48-924
Mfr. Part No.:
5207841-4
Brand:
TE Connectivity
Find similar products by selecting one or more attributes.
Select all

Brand

TE Connectivity

Number of Contacts

9

Product Type

D-Sub Connector

Orientation

Vertical

Current

6A

Mount Type

Board

Connector Type D

D-Sub

D-Sub Shell Size

1

Mounting Hardware

Threaded Insert

Housing Material

Thermoplastic

Termination Type

Solder

Minimum Operating Temperature

-55°C

Maximum Operating Temperature

105°C

Standards/Approvals

UL 94 V-0

Contact Material

Phosphor Bronze

Series

HD20

Contact Plating

Gold

Pitch

2.74mm

COO (Country of Origin):
MX
The TE Connectivity Receptacle assembly offers an effective and reliable solution for board-to-board connectivity. Designed specifically for vertical orientation, it strikes a balance between compact size and robust performance. The connector features a durable thermoplastic housing and brass contacts, ensuring a long-lasting and stable connection. The assembly is engineered to accommodate 9 positions across 2 rows, making it versatile for various application requirements. Ideal for signal circuit applications, this connector's construction supports high operating temperatures and complies with stringent industry standards, making it an optimal choice for demanding environments. Whether you are developing consumer electronics or industrial equipment, this connection solution delivers precision and resilience.

Robust brass contact materials enhance durability and conductivity

Vertical housing orientation optimises space efficiency on PCBs

UL 94V-0 flammability rating ensures compliance with safety standards

PCB mount design facilitates straightforward installation

Compatible with wave soldering processes for increased assembly efficiency

Thermoplastic material provides resistance against environmental stress

Mating retention features ensure secure connections even in challenging applications

Suitable for a range of temperatures from -55 to 105 °C, enhancing reliability
