TE Connectivity 1218441-6 9 Way Right Angle 2.77 mm Pitch Board D-Sub Connector Male
- RS Stock No.:
- 475-193
- Distrelec Article No.:
- 304-49-322
- Mfr. Part No.:
- 1218441-6
- Brand:
- TE Connectivity
Subtotal (1 pack of 2 units)*
£146.85
(exc. VAT)
£176.22
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 28 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £146.85 | £73.425 |
*price indicative
- RS Stock No.:
- 475-193
- Distrelec Article No.:
- 304-49-322
- Mfr. Part No.:
- 1218441-6
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Number of Contacts | 9 | |
| Product Type | D-Sub Connector | |
| Current | 5A | |
| Orientation | Right Angle | |
| Mount Type | Board | |
| Connector Gender | Male | |
| D-Sub Shell Size | 1 | |
| Termination Type | Solder | |
| Minimum Operating Temperature | -55°C | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | No | |
| Contact Material | Beryllium Copper Alloy, Brass | |
| Series | 1218441-6 | |
| Contact Plating | Gold | |
| Contact Size | 20 | |
| Pitch | 2.77mm | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Number of Contacts 9 | ||
Product Type D-Sub Connector | ||
Current 5A | ||
Orientation Right Angle | ||
Mount Type Board | ||
Connector Gender Male | ||
D-Sub Shell Size 1 | ||
Termination Type Solder | ||
Minimum Operating Temperature -55°C | ||
Contact Gender Male | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals No | ||
Contact Material Beryllium Copper Alloy, Brass | ||
Series 1218441-6 | ||
Contact Plating Gold | ||
Contact Size 20 | ||
Pitch 2.77mm | ||
Non Compliant
- COO (Country of Origin):
- US
The TE Connectivity connector is expertly designed for cable-to-board applications, providing reliable functionality in various electronic systems. It features a board mount configuration with a robust construction that ensures durability and high performance. Equipped with nine positions and a pin size that optimally suits size 20 contacts, this connector caters to specific installation requirements, all while maintaining a compact footprint. Its thoughtful design prioritises efficient signal transmission within printed circuit boards. This product seamlessly integrates into your projects, offering a dependable solution for interconnection needs.
Robust steel construction provides enhanced durability
Right-angle PCB mount orientation optimises space utilisation
The connector is tailored for reliable signal transmission
Gold plating on contact mating areas ensures superior conductivity
Designed for wave solder capability, supporting high-volume manufacturing
Operating temperature range enhances versatility across different environments
Exceeds standard performance metrics for modern electronic applications
Adheres to important compliance regulations, ensuring safety and reliability
