SKF 6320 M/C3 Single Row Deep Groove Ball Bearing- Open Type 100mm I.D, 215mm O.D
- RS Stock No.:
- 207-5363
- Mfr. Part No.:
- 6320 M/C3
- Brand:
- SKF
Subtotal (1 unit)*
£1,029.89
(exc. VAT)
£1,235.87
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £1,029.89 |
*price indicative
- RS Stock No.:
- 207-5363
- Mfr. Part No.:
- 6320 M/C3
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | SKF | |
Inside Diameter | 100mm | |
Outside Diameter | 215mm | |
Race Width | 47mm | |
Ball Bearing Type | Single Row Deep Groove Ball Bearing | |
Sealing Arrangement | Open Type | |
Bearing Clearance | C3 | |
Material | Steel | |
Ball Material | Steel | |
Cage Material | Machined Metal | |
Number of Rows | 1 | |
Static Load Rating | 140kN | |
Dynamic Load Rating | 174kN | |
Bore Type | Parallel | |
Bearing Series | 3 Medium | |
Partial Bearing Code | 6320 | |
Select all | ||
---|---|---|
Brand SKF | ||
Inside Diameter 100mm | ||
Outside Diameter 215mm | ||
Race Width 47mm | ||
Ball Bearing Type Single Row Deep Groove Ball Bearing | ||
Sealing Arrangement Open Type | ||
Bearing Clearance C3 | ||
Material Steel | ||
Ball Material Steel | ||
Cage Material Machined Metal | ||
Number of Rows 1 | ||
Static Load Rating 140kN | ||
Dynamic Load Rating 174kN | ||
Bore Type Parallel | ||
Bearing Series 3 Medium | ||
Partial Bearing Code 6320 | ||
- COO (Country of Origin):
- FR
SKF Ball Bearing, 100 mm ID, 215 mm OD - 6320 M/C3
Equip your industrial machinery with this SKF deep-groove ball bearing to handle both axial and radial loads efficiently. The unit is designed with smooth raceways that ensure friction remains low and minimal heat is generated. Its machined-brass cage provides high strength and rigidity while remaining lightweight. Additionally, the brass absorbs lubricant, which is useful in demanding environments where low lubricant conditions are likely. This ball bearing is simple to mount and maintain, making it the ideal choice for heavy-duty applications.
• Open-end type for smooth operation
• Limiting speed of 6000 rpm for high rotation
• Inside diameter of 100 mm, outside diameter of 215 mm
• Race width of 47 mm allows for use in many situations
• Corrosion-resistant stainless-steel body material
• Limiting speed of 6000 rpm for high rotation
• Inside diameter of 100 mm, outside diameter of 215 mm
• Race width of 47 mm allows for use in many situations
• Corrosion-resistant stainless-steel body material
Application Information
• Energy sector
• Manufacturing industry
• Food-processing equipment
• Manufacturing industry
• Food-processing equipment
What's the internal clearance of this ball bearing?
This ball bearing has C3 internal clearance, which is classified by SKF as greater than normal.
When should I use a deep groove ball bearing with C3 internal clearance?
C3 clearance is ideal for applications with low torque and high loads, such as certain automotive machinery. It provides room for thermal expansion in case the unit is operating at very high temperatures.
