SKF 51324 M 1 Row Thrust Ball Bearing - 120 mm ID, 210 mm OD
- RS Stock No.:
- 462-766
- Mfr. Part No.:
- 51324 M
- Brand:
- SKF
Subtotal (1 unit)*
£1,244.20
(exc. VAT)
£1,493.04
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 30 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1,244.20 |
*price indicative
- RS Stock No.:
- 462-766
- Mfr. Part No.:
- 51324 M
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 120 mm | |
| Product Type | Thrust Ball Bearing | |
| Outside Diameter | 210 mm | |
| Race Width | 70mm | |
| Cage Material | Machined Brass | |
| Number of Rows | 1 | |
| Static Load Rating | 980kN | |
| Dynamic Load Rating | 332kN | |
| Standards/Approvals | UNSPSC, RoHS, eClass | |
| Bore Type | Ground | |
| Limiting Speed | 1500rpm | |
| Bearing Type | Thrust Ball | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 120 mm | ||
Product Type Thrust Ball Bearing | ||
Outside Diameter 210 mm | ||
Race Width 70mm | ||
Cage Material Machined Brass | ||
Number of Rows 1 | ||
Static Load Rating 980kN | ||
Dynamic Load Rating 332kN | ||
Standards/Approvals UNSPSC, RoHS, eClass | ||
Bore Type Ground | ||
Limiting Speed 1500rpm | ||
Bearing Type Thrust Ball | ||
- COO (Country of Origin):
- CZ
Gavin
The SKF Single direction thrust ball bearing can accommodate axial loads in one direction. They must not be subjected to any radial load. Their separable components facilitate mounting/dismounting and maintenance inspections. Many of the components are interchangeable. The shaft washers have a ground bore that enables an interference fit.
Steel bearing
Ground bore of shaft washers enable interference fit
