SKF 7024 BGM 1 Row Angular Contact Ball Bearing - 120 mm ID, 180 mm OD 28 mm Race Width
- RS Stock No.:
- 461-888
- Mfr. Part No.:
- 7024 BGM
- Brand:
- SKF
Subtotal (1 unit)*
£945.06
(exc. VAT)
£1,134.07
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 30 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £945.06 |
*price indicative
- RS Stock No.:
- 461-888
- Mfr. Part No.:
- 7024 BGM
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Angular Contact Ball Bearing | |
| Inside Diameter | 120 mm | |
| Outside Diameter | 180 mm | |
| Race Width | 28mm | |
| Ball Material | Steel | |
| Race Material | Steel | |
| End Type | Open | |
| Number of Rows | 1 | |
| Static Load Rating | 93kN | |
| Contact Angle | 40° | |
| Dynamic Load Rating | 87.1kN | |
| Series | 7024 | |
| Standards/Approvals | RoHS | |
| Limiting Speed | 4000rpm | |
| Race Type | Grooved | |
| Bearing Type | Angular Contact | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Angular Contact Ball Bearing | ||
Inside Diameter 120 mm | ||
Outside Diameter 180 mm | ||
Race Width 28mm | ||
Ball Material Steel | ||
Race Material Steel | ||
End Type Open | ||
Number of Rows 1 | ||
Static Load Rating 93kN | ||
Contact Angle 40° | ||
Dynamic Load Rating 87.1kN | ||
Series 7024 | ||
Standards/Approvals RoHS | ||
Limiting Speed 4000rpm | ||
Race Type Grooved | ||
Bearing Type Angular Contact | ||
- COO (Country of Origin):
- AT
Gavin
The SKF Angular Contact Ball Bearing is designed to seamlessly integrate into machinery demanding exceptional performance and reliability. Engineered with advanced technology, it guarantees optimal speed and load capability, making it an ideal choice for applications where efficiency is paramount. The durable construction ensures longevity, while its lightweight design contributes to reduced energy consumption. Specifically tailored for dynamic environments, this bearing excels in offering robust support, catering to diverse industrial needs with ease.
Crafted for maximum rigidity enabling superior load handling
Offers reduced friction for enhanced energy efficiency
Incorporates high quality materials for extended service life
Designed to absorb vibrations ensuring smooth operational performance
Facilitates quick and easy installation saving time and effort
Provides excellent resistance to contaminants enhancing reliability
