SKF 305262 D 2 Row Angular Contact Ball Bearing - 180 mm ID, 259.5 mm OD 66 mm Race Width
- RS Stock No.:
- 461-545
- Mfr. Part No.:
- 305262 D
- Brand:
- SKF
Subtotal (1 unit)*
£1,612.77
(exc. VAT)
£1,935.32
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 30 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £1,612.77 |
*price indicative
- RS Stock No.:
- 461-545
- Mfr. Part No.:
- 305262 D
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Inside Diameter | 180 mm | |
| Product Type | Angular Contact Ball Bearing | |
| Outside Diameter | 259.5 mm | |
| Race Width | 66mm | |
| Ball Material | Steel | |
| Race Material | Bearing Steel | |
| Cage Material | Machined Metal | |
| End Type | Open | |
| Number of Rows | 2 | |
| Static Load Rating | 310kN | |
| Contact Angle | 32° | |
| Internal Clearance | NSTD | |
| Dynamic Load Rating | 225kN | |
| Standards/Approvals | RoHS | |
| Series | 305 | |
| Limiting Speed | 2600rpm | |
| Bearing Type | Angular Contact | |
| Race Type | Grooved | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Inside Diameter 180 mm | ||
Product Type Angular Contact Ball Bearing | ||
Outside Diameter 259.5 mm | ||
Race Width 66mm | ||
Ball Material Steel | ||
Race Material Bearing Steel | ||
Cage Material Machined Metal | ||
End Type Open | ||
Number of Rows 2 | ||
Static Load Rating 310kN | ||
Contact Angle 32° | ||
Internal Clearance NSTD | ||
Dynamic Load Rating 225kN | ||
Standards/Approvals RoHS | ||
Series 305 | ||
Limiting Speed 2600rpm | ||
Bearing Type Angular Contact | ||
Race Type Grooved | ||
- COO (Country of Origin):
- AT
Omkar
The SKF Double row angular contact ball bearing, with two-piece inner ring and relubrication feature, correspond to a pair of single row angular contact ball bearings in a back-to-back arrangement. The two-piece inner ring enables incorporation of more balls, resulting in higher load carrying capacity. The annular lubrication groove and holes in the outer ring facilitates relubrication.
Relubrication feature
Suitable where a stiff bearing arrangement is required
Require less axial space than equivalent pair of single row angular contact ball bearings
