SKF 16052 MA 1 Row Deep Groove Ball Bearing - 260 mm ID, 400 mm OD
- RS Stock No.:
- 461-465
- Mfr. Part No.:
- 16052 MA
- Brand:
- SKF
Subtotal (1 unit)*
£3,321.86
(exc. VAT)
£3,986.23
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 05 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £3,321.86 |
*price indicative
- RS Stock No.:
- 461-465
- Mfr. Part No.:
- 16052 MA
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Deep Groove Ball Bearing | |
| Inside Diameter | 260 mm | |
| Outside Diameter | 400 mm | |
| Race Width | 44mm | |
| Cage Material | Machined Brass | |
| Ball Material | Steel | |
| Number of Rows | 1 | |
| Static Load Rating | 310kN | |
| Internal Clearance | 105 μm | |
| Dynamic Load Rating | 238kN | |
| Series | 16052 | |
| Standards/Approvals | No | |
| Bore Type | Cylindrical | |
| Limiting Speed | 2800rpm | |
| Bearing Type | Deep Groove Ball | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Deep Groove Ball Bearing | ||
Inside Diameter 260 mm | ||
Outside Diameter 400 mm | ||
Race Width 44mm | ||
Cage Material Machined Brass | ||
Ball Material Steel | ||
Number of Rows 1 | ||
Static Load Rating 310kN | ||
Internal Clearance 105 μm | ||
Dynamic Load Rating 238kN | ||
Series 16052 | ||
Standards/Approvals No | ||
Bore Type Cylindrical | ||
Limiting Speed 2800rpm | ||
Bearing Type Deep Groove Ball | ||
- COO (Country of Origin):
- FR
Rupali
The SKF Single row deep groove ball bearings are particularly versatile, have low friction and are optimized for low noise and low vibration, which enables high rotational speeds. They accommodate radial and axial loads in both directions, are easy to mount, and require less maintenance than many other bearing types.
Simple and versatile and robust design
Low friction
High speed capability
Accommodate radial and axial loads in both directions
Require little maintenance
