FAG 1220-K-M-C3 100 mm ID Self-Aligning Ball Bearing -, 180 mm OD
- RS Stock No.:
- 312-770
- Mfr. Part No.:
- 1220-K-M-C3
- Brand:
- FAG
Subtotal (1 unit)*
£510.12
(exc. VAT)
£612.14
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £510.12 |
*price indicative
- RS Stock No.:
- 312-770
- Mfr. Part No.:
- 1220-K-M-C3
- Brand:
- FAG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | FAG | |
| Inside Diameter | 100 mm | |
| Product Type | Self-Aligning Ball Bearing | |
| Outside Diameter | 180 mm | |
| Race Width | 34mm | |
| Static Load Rating | 29500N | |
| Dynamic Load Rating | 70000N | |
| Standards/Approvals | RoHS | |
| Limiting Speed | 6000rpm | |
| Bearing Type | Self-Aligning | |
| Select all | ||
|---|---|---|
Brand FAG | ||
Inside Diameter 100 mm | ||
Product Type Self-Aligning Ball Bearing | ||
Outside Diameter 180 mm | ||
Race Width 34mm | ||
Static Load Rating 29500N | ||
Dynamic Load Rating 70000N | ||
Standards/Approvals RoHS | ||
Limiting Speed 6000rpm | ||
Bearing Type Self-Aligning | ||
RoHS Status: Exempt
- COO (Country of Origin):
- IT
The FAG Self Aligning Ball Bearing is designed to offer exceptional performance and reliability in a wide range of applications. With a tapered bore taper of 1:12 and a solid brass cage, it is engineered to support substantial radial loads while accommodating misalignment. Its robust construction features a normal tolerance class, ensuring a tight fit and durability. The bearing operates efficiently without lubrication, making it a low-maintenance choice for operators.
Accommodates misalignment to extend service life
Allows for ease of installation with minimal maintenance
Capable of handling high radial loads for demanding applications
