FAG 1315-K-M-C3 75 mm ID Self-Aligning Ball Bearing -, 160 mm OD
- RS Stock No.:
- 311-146
- Mfr. Part No.:
- 1315-K-M-C3
- Brand:
- FAG
Subtotal (1 unit)*
£454.37
(exc. VAT)
£545.24
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £454.37 |
*price indicative
- RS Stock No.:
- 311-146
- Mfr. Part No.:
- 1315-K-M-C3
- Brand:
- FAG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | FAG | |
| Inside Diameter | 75 mm | |
| Product Type | Self-Aligning Ball Bearing | |
| Outside Diameter | 160 mm | |
| Race Width | 37mm | |
| Static Load Rating | 30000N | |
| Dynamic Load Rating | 80000N | |
| Standards/Approvals | RoHS | |
| Limiting Speed | 6700rpm | |
| Bearing Type | Self-Aligning | |
| Select all | ||
|---|---|---|
Brand FAG | ||
Inside Diameter 75 mm | ||
Product Type Self-Aligning Ball Bearing | ||
Outside Diameter 160 mm | ||
Race Width 37mm | ||
Static Load Rating 30000N | ||
Dynamic Load Rating 80000N | ||
Standards/Approvals RoHS | ||
Limiting Speed 6700rpm | ||
Bearing Type Self-Aligning | ||
RoHS Status: Exempt
- COO (Country of Origin):
- DE
The FAG Self Aligning Ball Bearing is expertly designed to accommodate misalignment and ensure smooth operation in various applications. Its unique tapered bore allows for optimal load distribution, making it perfect for machines subject to shaft deflection. With a solid brass cage, this bearing offers not only durability but also reliable performance under varying conditions. It is particularly well-suited for use in environments where maintenance might be limited, as it operates effectively without grease lubrication.
Excellent performance in high temperature and varying operational environments
Inherently accommodates misalignment for improved durability
Suitable for applications with radial and axial loads
