OPTIBELT Raw Edge Belt, belt section XPZ 1575 mm, 1524 mm Length
- RS Stock No.:
- 283-7053
- Mfr. Part No.:
- XPZ 1562 XEP
- Brand:
- OPTIBELT
Subtotal (1 unit)*
£13.25
(exc. VAT)
£15.90
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 12 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £13.25 |
*price indicative
- RS Stock No.:
- 283-7053
- Mfr. Part No.:
- XPZ 1562 XEP
- Brand:
- OPTIBELT
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | OPTIBELT | |
| Belt Section | XPZ | |
| Product Type | Raw Edge Belt | |
| Sub Type | Raw Edge Belt | |
| Series | SUPER XE-POWER PRO | |
| Cord Material | Rubber | |
| Belt Material | Rubber | |
| Minimum Operating Temperature | -40°C | |
| Outside Length | 1575mm | |
| Belt Width | 9.7mm | |
| Belt Height | 8mm | |
| Maximum Operating Temperature | 120°C | |
| Standards/Approvals | ISO 4184, RoHS, ISO 4183, ISO 1813, DIN 7753 Part 1 | |
| Inside Length | 1524mm | |
| Select all | ||
|---|---|---|
Brand OPTIBELT | ||
Belt Section XPZ | ||
Product Type Raw Edge Belt | ||
Sub Type Raw Edge Belt | ||
Series SUPER XE-POWER PRO | ||
Cord Material Rubber | ||
Belt Material Rubber | ||
Minimum Operating Temperature -40°C | ||
Outside Length 1575mm | ||
Belt Width 9.7mm | ||
Belt Height 8mm | ||
Maximum Operating Temperature 120°C | ||
Standards/Approvals ISO 4184, RoHS, ISO 4183, ISO 1813, DIN 7753 Part 1 | ||
Inside Length 1524mm | ||
- COO (Country of Origin):
- DE
The OPTIBELT SUPER XE-POWER PRO is one of the best performing wedge belts on the market. The innovative design of it opens up new scope in designing frictional power transmission drives, even on the smallest pulley diameters, in extreme temperature ranges and at the highest speeds.
Maintenance free
Very quiet running even at very high torque levels
M=S
Fit for back idlers
