Assemtech Any Position Vibration Sensor 40 mA
- RS Stock No.:
- 331-7525
- Mfr. Part No.:
- S1430
- Brand:
- Assemtech
Subtotal (1 unit)*
£73.04
(exc. VAT)
£87.65
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 6 unit(s) shipping from 29 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £73.04 |
*price indicative
- RS Stock No.:
- 331-7525
- Mfr. Part No.:
- S1430
- Brand:
- Assemtech
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Assemtech | |
| Product Type | Vibration Sensor | |
| Mounting Orientation | Any Position | |
| Maximum Current | 40mA | |
| Maximum DC Voltage | 5V dc | |
| Minimum Operating Temperature | -10°C | |
| Maximum Operating Temperature | 70°C | |
| Depth | 20.3mm | |
| Length | 50.8mm | |
| Diameter | 32mm | |
| Standards/Approvals | RoHS | |
| Width | 32mm | |
| Series | S14 | |
| Select all | ||
|---|---|---|
Brand Assemtech | ||
Product Type Vibration Sensor | ||
Mounting Orientation Any Position | ||
Maximum Current 40mA | ||
Maximum DC Voltage 5V dc | ||
Minimum Operating Temperature -10°C | ||
Maximum Operating Temperature 70°C | ||
Depth 20.3mm | ||
Length 50.8mm | ||
Diameter 32mm | ||
Standards/Approvals RoHS | ||
Width 32mm | ||
Series S14 | ||
- COO (Country of Origin):
- GB
Movement / Vibration Sensor with Adjustment
Adjustable sensitivity via an internal potentiometer
IP65 ABS housing which is prewired with 300mm (Vibration/Movement version) or 100mm (Tilt version) of 3 core PVC cable
Non-position sensitive with a 24mA output at 5Vdc
Tilt switch features anti vibration circuitry
