Molex 19121 Red Insulated Male Spade Connector, Crimp 10 AWG to 12 AWG
- RS Stock No.:
- 259-2458
- Mfr. Part No.:
- 19121-0053
- Brand:
- Molex
Bulk discount available
Subtotal (1 pack of 10 units)*
£3.92
(exc. VAT)
£4.70
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 340 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 10 - 90 | £0.392 | £3.92 |
| 100 - 240 | £0.343 | £3.43 |
| 250 + | £0.311 | £3.11 |
*price indicative
- RS Stock No.:
- 259-2458
- Mfr. Part No.:
- 19121-0053
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Termination Type | Crimp | |
| Product Type | Spade Connector | |
| Gender | Male | |
| Tab Width | 9.53mm | |
| Insulation | Insulated | |
| Maximum Wire Size AWG | 12AWG | |
| Minimum Wire Size AWG | 10AWG | |
| Colour | Red | |
| Contact Material | Brass | |
| Contact Plating | Tin | |
| Orientation | Straight | |
| Insulation Material | Polyvinyl Chloride | |
| Standards/Approvals | No | |
| Overall Length | 25.7mm | |
| Series | 19121 | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Termination Type Crimp | ||
Product Type Spade Connector | ||
Gender Male | ||
Tab Width 9.53mm | ||
Insulation Insulated | ||
Maximum Wire Size AWG 12AWG | ||
Minimum Wire Size AWG 10AWG | ||
Colour Red | ||
Contact Material Brass | ||
Contact Plating Tin | ||
Orientation Straight | ||
Insulation Material Polyvinyl Chloride | ||
Standards/Approvals No | ||
Overall Length 25.7mm | ||
Series 19121 | ||
RoHS Status: Exempt
The Molex insulkrimp flanged spade tongue terminal for 10-12 AWG wire. It has stud size of 8 (M4)and having width 9.53mm.
Barrel type closed
Color - resin natural
Flammability 94V-0
Insulation PVC
Net weight 1.903/g
Packaging type bag
Stud size 8 (M4)
Wire size AWG 10, 12
Wire size 4.00 mm² to 6 mm²
