EMERSON – ASCO Solenoid Valve 19090017, 3 port(s) , NC
- RS Stock No.:
- 278-4429
- Mfr. Part No.:
- 19090017
- Brand:
- EMERSON ? ASCO
Currently unavailable
Sorry, we don't know when this will be back in stock.
Alternative
This product is not currently available. Here is our alternative recommendation.
Each
£42.22
(exc. VAT)
£50.66
(inc. VAT)
- RS Stock No.:
- 278-4429
- Mfr. Part No.:
- 19090017
- Brand:
- EMERSON ? ASCO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | EMERSON ? ASCO | |
| Number of Ports | 3 | |
| Operation | Pilot | |
| Default Valve Position | NC | |
| Suitable Applications | Filtered Air, Neutral Gas | |
| Type | 3/2 | |
| Orifice Diameter | 1.6mm | |
| Series | 190 | |
| Body Material | Aluminium | |
| Maximum Working Pressure | 10 bar | |
| Operating Temperature Range | -10 → +60 °C | |
| Maximum Operating Temperature | +60°C | |
| Minimum Operating Temperature | -10°C | |
| Maximum Opening Time | 5ms | |
| Maximum Closing Time | 5ms | |
Select all | ||
|---|---|---|
Brand EMERSON ? ASCO | ||
Number of Ports 3 | ||
Operation Pilot | ||
Default Valve Position NC | ||
Suitable Applications Filtered Air, Neutral Gas | ||
Type 3/2 | ||
Orifice Diameter 1.6mm | ||
Series 190 | ||
Body Material Aluminium | ||
Maximum Working Pressure 10 bar | ||
Operating Temperature Range -10 → +60 °C | ||
Maximum Operating Temperature +60°C | ||
Minimum Operating Temperature -10°C | ||
Maximum Opening Time 5ms | ||
Maximum Closing Time 5ms | ||
Asco Solenoid Coils
Asco’s solenoid coil is predominantly used with solenoid valves within pneumatic applications. Another common application is to start, stop or direct the flow of hydraulic fluid. It has been created and designed to withstand and operate in aggressive conditions and fluctuating temperatures.
Features & Benefits
• This coil is ideal as a replacement solenoid coil
• Made up of durable, hardwearing materials
• Range of 3/2 NF solenoid valves used to control ISO distributors
• It is possible to use solenoid valves independently using simple or juxtaposable manifolds
• Choice of 3 coil voltages (ordered separately)
• M5 threaded exhaust aperture
• Compatible bases: CNOMO 06.05.80 and AFNOR NFE 49066
• Made up of durable, hardwearing materials
• Range of 3/2 NF solenoid valves used to control ISO distributors
• It is possible to use solenoid valves independently using simple or juxtaposable manifolds
• Choice of 3 coil voltages (ordered separately)
• M5 threaded exhaust aperture
• Compatible bases: CNOMO 06.05.80 and AFNOR NFE 49066
A little more information...
• A Solenoid coil needs to be replaced within a hydraulic system when the solenoid valve either wears down or stops working
• Did you know that a solenoid is electromagnetic? It's made up of a tightly wrapped metal coil around a solid metal core
• A solenoid coil is most commonly used as a low-power switch that opens and closes a pilot valve, which also controls the main valve through applying pressure to a connected piston
• Did you know that a solenoid is electromagnetic? It's made up of a tightly wrapped metal coil around a solid metal core
• A solenoid coil is most commonly used as a low-power switch that opens and closes a pilot valve, which also controls the main valve through applying pressure to a connected piston
ISO
