TE Connectivity, PIDG Insulated Ring Terminal, M8 Stud Size 22 AWG 22 AWG Wire Size, Green
- RS Stock No.:
- 504-086
- Distrelec Article No.:
- 304-61-271
- Mfr. Part No.:
- 2-320572-2
- Brand:
- TE Connectivity
Subtotal (1 pack of 250 units)*
£158.15
(exc. VAT)
£189.78
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 31 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £158.15 | £0.633 |
*price indicative
- RS Stock No.:
- 504-086
- Distrelec Article No.:
- 304-61-271
- Mfr. Part No.:
- 2-320572-2
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Series | PIDG | |
| Product Type | Ring Terminal | |
| Insulation | Insulated | |
| Insulation Material | Nylon | |
| Inner Ring Diameter | 7.92mm | |
| Minimum Wire Size AWG | 22 AWG | |
| Maximum Wire Size AWG | 22 AWG | |
| Overall Length | 27.38mm | |
| Stud Size | M8 | |
| Colour | Green | |
| Contact Material | Copper | |
| Contact Plating | Tin | |
| Thickness | 0.79mm | |
| Standards/Approvals | 2016, China RoHS 2 Directive MIIT Order No 32, CSA, EU ELV Directive 2000/53/EC Compliant, EU RoHS Directive 2011/65/EU Compliant | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Series PIDG | ||
Product Type Ring Terminal | ||
Insulation Insulated | ||
Insulation Material Nylon | ||
Inner Ring Diameter 7.92mm | ||
Minimum Wire Size AWG 22 AWG | ||
Maximum Wire Size AWG 22 AWG | ||
Overall Length 27.38mm | ||
Stud Size M8 | ||
Colour Green | ||
Contact Material Copper | ||
Contact Plating Tin | ||
Thickness 0.79mm | ||
Standards/Approvals 2016, China RoHS 2 Directive MIIT Order No 32, CSA, EU ELV Directive 2000/53/EC Compliant, EU RoHS Directive 2011/65/EU Compliant | ||
- COO (Country of Origin):
- US
The TE Connectivity Closed Ring Tongue Terminal is an exceptional product designed for reliable electrical connections in various applications. Engineered for optimal performance, this terminal features a closed barrel construction, ensuring secure and efficient connectivity for wires up to 22 AWG. With a stud size that accommodates 5/16 or M8 studs, it is well-suited for use in both commercial and industrial settings. The tin plating enhances durability and resistance to corrosion, extending the product’s lifespan and improving its overall functionality. Its partially insulated design further enhances safety and usability, making it a preferred choice for professionals who demand quality and reliability in electrical components. Whether you are working with copper wire or looking for versatility in application, this terminal stands out for its precision engineering and robust design.
Designed for secure and reliable connections in a wide range of environments
Closed barrel construction provides outstanding wire retention
Tin plating offers enhanced corrosion resistance for longer-lasting performance
Partially insulated design ensures safety during installation and operation
Compatibility with M8 studs allows for versatile applications
