TE Connectivity PCB Mount Power Relay, 5V dc Coil, 30A Switching Current, SPST
- RS Stock No.:
- 276-3884
- Mfr. Part No.:
- T9GS1L14-5 1558666-1
- Brand:
- TE Connectivity
Bulk discount available
Subtotal (1 unit)*
£2.50
(exc. VAT)
£3.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 734 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £2.50 |
5 + | £2.39 |
*price indicative
- RS Stock No.:
- 276-3884
- Mfr. Part No.:
- T9GS1L14-5 1558666-1
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TE Connectivity | |
Coil Voltage | 5V dc | |
Contact Configuration | SPST | |
Mounting Type | PCB Mount | |
Switching Current | 30A | |
Number of Poles | 1 | |
Latching | No | |
Series | Potter & Brumfield T9G | |
Terminal Type | Through Hole | |
Maximum Switching Voltage AC | 480V ac | |
Length | 29mm | |
Coil Resistance | 28 Ω | |
Coil Power | 900mW | |
Height | 15.7mm | |
Minimum Operating Temperature | -40°C | |
Contact Material | Silver Alloy | |
Maximum Operating Temperature | +105°C | |
Depth | 21.5mm | |
Width | 21.5mm | |
Dimensions | 29 x 21.5 x 15.7mm | |
Select all | ||
---|---|---|
Brand TE Connectivity | ||
Coil Voltage 5V dc | ||
Contact Configuration SPST | ||
Mounting Type PCB Mount | ||
Switching Current 30A | ||
Number of Poles 1 | ||
Latching No | ||
Series Potter & Brumfield T9G | ||
Terminal Type Through Hole | ||
Maximum Switching Voltage AC 480V ac | ||
Length 29mm | ||
Coil Resistance 28 Ω | ||
Coil Power 900mW | ||
Height 15.7mm | ||
Minimum Operating Temperature -40°C | ||
Contact Material Silver Alloy | ||
Maximum Operating Temperature +105°C | ||
Depth 21.5mm | ||
Width 21.5mm | ||
Dimensions 29 x 21.5 x 15.7mm | ||
The TE Connectivity Potter and Brumfield T9G relay series is a 30A Power PCB relay for HVAC, appliance and industrial control applications. The T9G relay is the smallest relay in its class with a 30% smaller package size and 13% less PCB floor space all while keeping the standard footprint, allowing manufacturers to add more components on PCBs without having to compromise on relay performance.
User friendly
Easy to install
Easy to install
