Eaton DIN Rail Impulse Relay, 110V ac Coil, 16A Switching Current, DPDT
- RS Stock No.:
- 253-592
- Mfr. Part No.:
- 265313 Z-S110/WW
- Brand:
- Eaton
Subtotal (1 unit)*
£137.19
(exc. VAT)
£164.63
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 11 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £137.19 |
*price indicative
- RS Stock No.:
- 253-592
- Mfr. Part No.:
- 265313 Z-S110/WW
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Coil Voltage | 110V ac | |
| Product Type | Impulse Relay | |
| Contact Configuration | DPDT | |
| Mount Type | DIN Rail | |
| Series | ZS | |
| Switching Voltage | 240V | |
| Switching Current | 16A | |
| Standards/Approvals | RoHS | |
| Height | 70mm | |
| Width | 35mm | |
| Length | 80mm | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Coil Voltage 110V ac | ||
Product Type Impulse Relay | ||
Contact Configuration DPDT | ||
Mount Type DIN Rail | ||
Series ZS | ||
Switching Voltage 240V | ||
Switching Current 16A | ||
Standards/Approvals RoHS | ||
Height 70mm | ||
Width 35mm | ||
Length 80mm | ||
RoHS Status: Exempt
The Eaton impulse relay set a new standard in circuit control with its robust design and versatile specifications. Engineered for 110AC operation, it seamlessly integrates into electrical installations, ensuring reliable performance in demanding environments. The device features dual changeover contacts, providing exceptional functionality for both simple and complex circuitry. Its compact dimensions allow for easy installation on DIN rails, making it suitable for various applications. With a rated operational current of 16A, this relay combines efficiency with safety, meeting stringent compliance and reliability standards. Whether used in residential or commercial settings, it guarantees optimal performance backed by a trusted manufacturer, delivering lasting value.
Utilises a standard control voltage of 110V for ease of integration
Designed for efficient heat dissipation to enhance longevity
Supports multiple types of load management including incandescent and fluorescent lamps
Features a manual operation mode for added flexibility during maintenance
Constructed to ensure compliance with RoHS regulations for environmental safety
Incorporates a built-in depth of 60mm, optimising space usage in panels
Offers a high maximum switching current capacity, ensuring compatibility with various electrical applications
Effectively operates in a temperature range from -20°C to 45°C, suitable for diverse settings
