TDK, B84144A*R000 25 A 440V ac 50Hz, 60 Hz, Flange EMC Filter, Tab 3 Phase
- RS Stock No.:
- 242-3506
- Mfr. Part No.:
- B84144A0025R000
- Brand:
- TDK
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£254.28
(exc. VAT)
£305.14
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 2 unit(s) shipping from 20 July 2026
- Plus 3 unit(s) shipping from 27 July 2026
- Plus 4 unit(s) shipping from 22 January 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £254.28 |
| 5 - 9 | £251.14 |
| 10 + | £248.07 |
*price indicative
- RS Stock No.:
- 242-3506
- Mfr. Part No.:
- B84144A0025R000
- Brand:
- TDK
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TDK | |
| Product Type | EMC Filter | |
| Maximum Current | 25A | |
| Maximum Voltage | 440V ac | |
| Mount Type | Flange | |
| Termination Style | Tab | |
| Number of Phases | 3 | |
| Series | B84144A*R000 | |
| Number of Stages | 1 | |
| Operating Frequency | 50, 60Hz | |
| Minimum Operating Temperature | -25°C | |
| Leakage Current | 4.1mA | |
| Maximum Operating Temperature | 100°C | |
| Length | 156mm | |
| Depth | 216mm | |
| Height | 91mm | |
| Resistance | 6mΩ | |
| Standards/Approvals | UL1283 | |
| Select all | ||
|---|---|---|
Brand TDK | ||
Product Type EMC Filter | ||
Maximum Current 25A | ||
Maximum Voltage 440V ac | ||
Mount Type Flange | ||
Termination Style Tab | ||
Number of Phases 3 | ||
Series B84144A*R000 | ||
Number of Stages 1 | ||
Operating Frequency 50, 60Hz | ||
Minimum Operating Temperature -25°C | ||
Leakage Current 4.1mA | ||
Maximum Operating Temperature 100°C | ||
Length 156mm | ||
Depth 216mm | ||
Height 91mm | ||
Resistance 6mΩ | ||
Standards/Approvals UL1283 | ||
B84144-A Series
EPCOS B84144-A series RFI four line filters. Construced of a metal case with threaded bushes at end faces for RF- Tight installation. Fasy to install and has a space saving design. Optimized leakage, High insertion loss. Rated voltage VR: 440/250 V AC.Rated current IR: 16 A to 180 A. For converters and power electronics.
Applications
General applications for power electronics
Wind farms
UPS
For machine tools, textile and packaging machines
Standards
UL1283, CSA 22.2 No.8 1986
