Norgren Double Acting Cylinder - PRA/802000/M, 100mm Bore, 200mm Stroke, ISOLine Series, Double Acting
- RS Stock No.:
- 218-0662
- Mfr. Part No.:
- PRA/802100/M/200
- Brand:
- Norgren
Bulk discount available
Subtotal (1 unit)*
£291.30
(exc. VAT)
£349.56
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £291.30 |
| 5 - 9 | £285.49 |
| 10 + | £279.66 |
*price indicative
- RS Stock No.:
- 218-0662
- Mfr. Part No.:
- PRA/802100/M/200
- Brand:
- Norgren
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Norgren | |
| Manufacturer Series | ISOLine | |
| Model Number p | PRA/802000/M | |
| Action | Double | |
| Stroke | 200mm | |
| Bore | 100mm | |
| Pneumatic Connection | G 1/2 | |
| Piston Rod Thread Gender | Male | |
| Cushioning Type | Pneumatic Adjustable | |
| Dimensions | 429 x 113 x 113mm | |
| Length | 429mm | |
| Height | 113mm | |
| Width | 113mm | |
| Maximum Operating Pressure | 12 bar | |
| ISO Standard | 15552 | |
| Stroke Interval Weight | 0.23 kg (At 25 mm Stroke) | |
| Maximum Operating Temperature | +80°C | |
| Test Weight | 3.66 kg (At 0 mm) | |
| Weight | 5.5kg | |
| Minimum Operating Temperature | -20°C | |
Select all | ||
|---|---|---|
Brand Norgren | ||
Manufacturer Series ISOLine | ||
Model Number p PRA/802000/M | ||
Action Double | ||
Stroke 200mm | ||
Bore 100mm | ||
Pneumatic Connection G 1/2 | ||
Piston Rod Thread Gender Male | ||
Cushioning Type Pneumatic Adjustable | ||
Dimensions 429 x 113 x 113mm | ||
Length 429mm | ||
Height 113mm | ||
Width 113mm | ||
Maximum Operating Pressure 12 bar | ||
ISO Standard 15552 | ||
Stroke Interval Weight 0.23 kg (At 25 mm Stroke) | ||
Maximum Operating Temperature +80°C | ||
Test Weight 3.66 kg (At 0 mm) | ||
Weight 5.5kg | ||
Minimum Operating Temperature -20°C | ||
RoHS Status: Exempt
- COO (Country of Origin):
- DE
IMI Norgren Double-Acting Cylinder, Self-Adjusting Cushioning, G1/2 Pneumatic Port Size - ISOLine Series - PRA/802100/M/200
Keep your workpieces in line with this IMI Norgren double-acting cylinder. It uses air to retract and extend its piston, meaning strokes in both directions are closely controlled and suited for precision sorting tasks. Thanks to a 200mm stroke length and a 1.8ms response time, the unit covers a lot of ground and doesn't waste a moment. A standard M20x1.5 piston rod thread makes this a compatible fit with standard pneumatic equipment. As the cylinder comes with self-adjusting cushioning, it automatically adapts to suit changing loads so your application rolls along smoothly.
Features & Benefits
• Low-friction PUR seals maintain pressure and steady vibrations to cut down on operating noise
• Safe for use in pressures between 1 and 12 bar, so delivers reliable performance in various settings
• Topside needle lets you manually adjust cushioning for tough jobs
• Safe for use in pressures between 1 and 12 bar, so delivers reliable performance in various settings
• Topside needle lets you manually adjust cushioning for tough jobs
Applications
• Semiconductor manufacturing
• Construction industry
• Warehouses
• Construction industry
• Warehouses
Can I use this cylinder in wet conditions?
Yes, this cylinder comes with durable die-cast aluminium casing, giving it the corrosion resistance it needs to work in demanding wet applications.
