TE Connectivity, 7.62mm Pitch, Buchanan, 10 Way, Right Angle, Pluggable Terminal Block, Header, Board Mount, Solder,
- RS Stock No.:
- 477-688
- Mfr. Part No.:
- 1-282966-0
- Brand:
- TE Connectivity
Subtotal (1 box of 25 units)*
£140.75
(exc. VAT)
£168.90
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
---|---|---|
1 + | £140.75 | £5.63 |
*price indicative
- RS Stock No.:
- 477-688
- Mfr. Part No.:
- 1-282966-0
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TE Connectivity | |
Pluggable Terminal Block Type | Header | |
Number of Contacts | 10 | |
Pitch | 7.62mm | |
Series | Buchanan | |
Number of Rows | 1 | |
Body Orientation | Right Angle | |
Mounting Type | Board Mount | |
Termination Method | Solder, Through Hole | |
Select all | ||
---|---|---|
Brand TE Connectivity | ||
Pluggable Terminal Block Type Header | ||
Number of Contacts 10 | ||
Pitch 7.62mm | ||
Series Buchanan | ||
Number of Rows 1 | ||
Body Orientation Right Angle | ||
Mounting Type Board Mount | ||
Termination Method Solder, Through Hole | ||
- COO (Country of Origin):
- US
The TE Connectivity 10 Position PCB Terminal Block stands as a reliable solution for wire-to-board connections with its robust design. Engineered for versatility, it accommodates wire sizes ranging from 30 to 12 AWG, making it ideal for various applications, including power and signal circuits. With a centreline pitch of 7.62 mm, this component features a fully shrouded header type, ensuring enhanced safety and substantially reducing the risk of misconnection. Its compact design allows for seamless integration into printed circuit boards, maximising efficiency and space-saving capabilities. The terminal block is crafted from durable materials, ensuring longevity even in demanding environments, and operates effectively across a temperature range of -40 to 105 °C. With compliance to strict regulatory standards, this terminal block not only exemplifies quality but also aligns with environmental directives, making it a conscientious choice for modern applications.
Designed for maximum durability in various environments
Right-angle orientation enables easy mounting on PCBs
Side stackable configuration optimises your layout options
Tin-plated contacts enhance electrical conductivity
Wave solder capability allows for efficient manufacturing processes
Packaged conveniently in boxes to meet high-volume needs
Right-angle orientation enables easy mounting on PCBs
Side stackable configuration optimises your layout options
Tin-plated contacts enhance electrical conductivity
Wave solder capability allows for efficient manufacturing processes
Packaged conveniently in boxes to meet high-volume needs
