Phoenix Contact PTDA 1 Series PCB Terminal Block, 12-Contact, 3.5 mm Pitch, Wave Soldering Mount, 1 Row
- RS Stock No.:
- 520-077
- Mfr. Part No.:
- 1724964
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£112.79
(exc. VAT)
£135.35
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 26 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £112.79 | £2.256 |
*price indicative
- RS Stock No.:
- 520-077
- Mfr. Part No.:
- 1724964
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 12 | |
| Pitch | 3.5mm | |
| Number of Rows | 1 | |
| Current | 17.5A | |
| Housing Material | Polyamide | |
| Mount Type | Wave Soldering Mount | |
| Minimum Wire Size mm² | 0.2mm² | |
| Maximum Wire Size mm² | 1.5mm² | |
| Minimum Wire Size AWG | 24AWG | |
| Maximum Wire Size AWG | 16AWG | |
| Orientation | 45° | |
| Colour | Green | |
| Wire Connection Method | Push-in Spring | |
| Voltage | 24V | |
| Standards/Approvals | VDE report with production monitoring, cULus Recognised | |
| Series | PTDA 1 | |
| Width | 22.4mm | |
| Length | 16mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Terminal Block | ||
Number of Contacts 12 | ||
Pitch 3.5mm | ||
Number of Rows 1 | ||
Current 17.5A | ||
Housing Material Polyamide | ||
Mount Type Wave Soldering Mount | ||
Minimum Wire Size mm² 0.2mm² | ||
Maximum Wire Size mm² 1.5mm² | ||
Minimum Wire Size AWG 24AWG | ||
Maximum Wire Size AWG 16AWG | ||
Orientation 45° | ||
Colour Green | ||
Wire Connection Method Push-in Spring | ||
Voltage 24V | ||
Standards/Approvals VDE report with production monitoring, cULus Recognised | ||
Series PTDA 1 | ||
Width 22.4mm | ||
Length 16mm | ||
- COO (Country of Origin):
- PL
The Phoenix Contact printed circuit board terminal block offers a seamless integration of quality and efficiency, designed specifically for demanding electronic applications. With its robust construction and innovative push-in spring connection technology, it ensures reliable electrical performance while simplifying installation. The unique design features a compact format with six potentials, allowing for versatile use in various circuits. Engineered for high-performance reliability, this terminal block can handle currents of up to 17.5 A and voltages of 240 V, making it ideal for a wide range of uses from simple circuits to advanced bus applications. The terminal block is also compliant with RoHS and WEEE standards, ensuring it meets stringent environmental requirements.
Time-saving installation process requires no additional tools
Defined contact force provides long-term stability and reliability
Integrated test option enables convenient and quick performance checks
Flexible conductor compatibility accommodates various wire types
Enhanced mechanical stability reduces strain on solder connections
Compact design optimises space while maintaining efficiency
