TE Connectivity AMPMODU Series Right Angle Board PCB Header, 4 Contact(s), 2.54 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 504-389
- Mfr. Part No.:
- 103361-2
- Brand:
- TE Connectivity
Subtotal (1 tube of 80 units)*
£167.42
(exc. VAT)
£200.90
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 09 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 + | £167.42 | £2.093 |
*price indicative
- RS Stock No.:
- 504-389
- Mfr. Part No.:
- 103361-2
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | PCB Header | |
| Series | AMPMODU | |
| Pitch | 2.54mm | |
| Current | 3A | |
| Housing Material | Thermoplastic | |
| Number of Contacts | 4 | |
| Number of Rows | 1 | |
| Orientation | Right Angle | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Board | |
| Connector System | Board-to-Board | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Gold | |
| Row Pitch | 2.54mm | |
| Termination Type | Solder | |
| Minimum Operating Temperature | 65°C | |
| Tail Pin Length | 2.79mm | |
| Maximum Operating Temperature | 105°C | |
| Standards/Approvals | CSA LR7189, UL 94V-0, UL E28476 | |
| Voltage | 750 Vrms | |
| Distrelec Product Id | 304-48-470 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type PCB Header | ||
Series AMPMODU | ||
Pitch 2.54mm | ||
Current 3A | ||
Housing Material Thermoplastic | ||
Number of Contacts 4 | ||
Number of Rows 1 | ||
Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Board | ||
Connector System Board-to-Board | ||
Contact Material Phosphor Bronze | ||
Contact Plating Gold | ||
Row Pitch 2.54mm | ||
Termination Type Solder | ||
Minimum Operating Temperature 65°C | ||
Tail Pin Length 2.79mm | ||
Maximum Operating Temperature 105°C | ||
Standards/Approvals CSA LR7189, UL 94V-0, UL E28476 | ||
Voltage 750 Vrms | ||
Distrelec Product Id 304-48-470 | ||
Non Compliant
- COO (Country of Origin):
- US
The TE Connectivity PCB Mount Header is a premium solution designed to streamline board-to-board connections with precision and reliability. Ideal for various applications, its right-angle orientation and fully shrouded design ensure minimal footprint while maximising space efficiency on your PCB. The header accommodates four positions, offering flexibility in modular designs, and is crafted to endure rigorous electrical demands. Constructed with high-grade materials, this header not only meets robust durability standards but also accentuates superior performance with excellent contact reliability. With compatibility to various industry standards and environmental regulations, it integrates seamlessly into countless applications, proving to be an essential component for modern connectivity.
Right angle orientation optimises space on PCB layouts
Fully shrouded design protects against accidental disengagement
Gold plating on contacts provides enhanced conductivity and corrosion resistance
Capable of supporting a current rating of up to 3 A for dependable performance
Polarised mating alignment simplifies installation and reduces errors
Thermoplastic housing material ensures resilience in demanding environments
