TE Connectivity MTA-100 Series Vertical Surface PCB Header, 3 Contact(s), 2.54 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 479-714
- Mfr. Part No.:
- 3-647168-3
- Brand:
- TE Connectivity
Subtotal (1 pack of 150 units)*
£346.88
(exc. VAT)
£416.26
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £346.88 | £2.313 |
*price indicative
- RS Stock No.:
- 479-714
- Mfr. Part No.:
- 3-647168-3
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | PCB Header | |
| Series | MTA-100 | |
| Pitch | 2.54mm | |
| Current | 5A | |
| Number of Contacts | 3 | |
| Housing Material | Nylon 46 | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Surface | |
| Connector System | Wire-to-Board | |
| Contact Material | Copper Alloy | |
| Contact Plating | Gold | |
| Termination Type | Surface Mount | |
| Minimum Operating Temperature | -55°C | |
| Row Pitch | 2.54mm | |
| Maximum Operating Temperature | 105°C | |
| Standards/Approvals | RoHS | |
| Mating Pin Length | 7.37mm | |
| Voltage | 250 V | |
| Distrelec Product Id | 304-50-707 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type PCB Header | ||
Series MTA-100 | ||
Pitch 2.54mm | ||
Current 5A | ||
Number of Contacts 3 | ||
Housing Material Nylon 46 | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Surface | ||
Connector System Wire-to-Board | ||
Contact Material Copper Alloy | ||
Contact Plating Gold | ||
Termination Type Surface Mount | ||
Minimum Operating Temperature -55°C | ||
Row Pitch 2.54mm | ||
Maximum Operating Temperature 105°C | ||
Standards/Approvals RoHS | ||
Mating Pin Length 7.37mm | ||
Voltage 250 V | ||
Distrelec Product Id 304-50-707 | ||
- COO (Country of Origin):
- CN
The TE Connectivity PCB Mount Header is expertly designed for vertical mounting in wire-to-board applications. This connector provides reliability and efficiency in signal connections while ensuring a compact footprint. Its partially shrouded design enhances usability, making it suitable for various electronic projects. The gold plating on the connections guarantees superior conductivity, whilst its robust construction ensures durability in demanding environments. With a 2.54 mm centreline, it is an ideal choice for modern PCB layouts that require precise dimensioning. This connector is compatible with the MTA 100 series, providing seamless integration with other components in your design.
Designed for easy PCB integration
Offers a secure friction lock to maintain connection
Constructed from high-quality nylon for enhanced resilience
Features inline contact layout for efficient space utilisation
Maximises electrical performance with nickel underplated contacts
Extends operational lifespan with a wide temperature tolerance
Capable of handling significant current ratings up to 5 A
