TE Connectivity AMPMODU Series Right Angle Board PCB Header, 60 Contact(s), 2.54 mm Pitch, 2 Row
- RS Stock No.:
- 477-339
- Distrelec Article No.:
- 304-54-042
- Mfr. Part No.:
- 3-535512-0
- Brand:
- TE Connectivity
Subtotal (1 tube of 35 units)*
£294.78
(exc. VAT)
£353.74
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 29 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 + | £294.78 | £8.422 |
*price indicative
- RS Stock No.:
- 477-339
- Distrelec Article No.:
- 304-54-042
- Mfr. Part No.:
- 3-535512-0
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | PCB Header | |
| Series | AMPMODU | |
| Current | 2A | |
| Pitch | 2.54mm | |
| Number of Contacts | 60 | |
| Housing Material | Fibreglass Polyester | |
| Number of Rows | 2 | |
| Orientation | Right Angle | |
| Mount Type | Board | |
| Connector System | Board-to-Board | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Gold | |
| Termination Type | Solder | |
| Row Pitch | 2.54mm | |
| Minimum Operating Temperature | 65°C | |
| Contact Gender | Female | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 2.92mm | |
| Standards/Approvals | CSA LR7189, UL 94V-0, UL E28476 | |
| Mating Pin Length | 3mm | |
| Voltage | 333V | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type PCB Header | ||
Series AMPMODU | ||
Current 2A | ||
Pitch 2.54mm | ||
Number of Contacts 60 | ||
Housing Material Fibreglass Polyester | ||
Number of Rows 2 | ||
Orientation Right Angle | ||
Mount Type Board | ||
Connector System Board-to-Board | ||
Contact Material Phosphor Bronze | ||
Contact Plating Gold | ||
Termination Type Solder | ||
Row Pitch 2.54mm | ||
Minimum Operating Temperature 65°C | ||
Contact Gender Female | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 2.92mm | ||
Standards/Approvals CSA LR7189, UL 94V-0, UL E28476 | ||
Mating Pin Length 3mm | ||
Voltage 333V | ||
Non Compliant
- COO (Country of Origin):
- TW
The TE Connectivity PCB Mount Receptacle is an innovative solution designed for board-to-board connections, providing exceptional reliability and performance in compact applications. Engineered with a right-angle orientation, this 60-position receptacle ensures efficient use of space while maintaining robust electrical properties. Its gold-plated contacts offer superior conductivity and corrosion resistance, making it ideal for high-performance electronic devices. Built to withstand harsh operating conditions, the receptacle features a standard connector profile and is suitable for various applications, including signal interfacing in industrial automation and consumer electronics. The Modu Connector System enhances installation flexibility, while its through-hole soldering method guarantees secure attachment to printed circuit boards.
Designed for high-density applications, optimising space without compromising performance
Gold plating on contacts enhances conductivity and ensures longevity
Standard connector profile facilitates ease of integration into existing designs
High-temperature housing material withstands demanding operational environments
Designed for a variety of industry standards, ensuring broad compatibility
Seamless assembly maximises operational efficiency during installation
Stackable configuration provides flexible and modular options for assembly
