TE Connectivity MTA-100 Series Vertical Cable PCB Header, 15 Contact(s), 2.54 mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 477-293
- Mfr. Part No.:
- 4-641126-5
- Brand:
- TE Connectivity
Subtotal (1 pack of 40 units)*
£165.17
(exc. VAT)
£198.20
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 08 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £165.17 | £4.129 |
*price indicative
- RS Stock No.:
- 477-293
- Mfr. Part No.:
- 4-641126-5
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | PCB Header | |
| Series | MTA-100 | |
| Current | 5A | |
| Pitch | 2.54mm | |
| Housing Material | Fibreglass Polyester | |
| Number of Contacts | 15 | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | Wire-to-Board | |
| Mount Type | Cable | |
| Contact Material | Copper Alloy | |
| Contact Plating | Gold | |
| Termination Type | Solder | |
| Minimum Operating Temperature | -55°C | |
| Row Pitch | 2.54mm | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 3.56mm | |
| Contact Gender | Male | |
| Standards/Approvals | RoHS | |
| Mating Pin Length | 7.49mm | |
| Voltage | 250 V | |
| Distrelec Product Id | 304-50-762 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type PCB Header | ||
Series MTA-100 | ||
Current 5A | ||
Pitch 2.54mm | ||
Housing Material Fibreglass Polyester | ||
Number of Contacts 15 | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Connector System Wire-to-Board | ||
Mount Type Cable | ||
Contact Material Copper Alloy | ||
Contact Plating Gold | ||
Termination Type Solder | ||
Minimum Operating Temperature -55°C | ||
Row Pitch 2.54mm | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 3.56mm | ||
Contact Gender Male | ||
Standards/Approvals RoHS | ||
Mating Pin Length 7.49mm | ||
Voltage 250 V | ||
Distrelec Product Id 304-50-762 | ||
- COO (Country of Origin):
- CN
The TE Connectivity PCB Mount Header is designed to facilitate efficient wire-to-board connections, providing an exceptional assembly solution for a variety of applications. Offering a vertical orientation and partially shrouded header type, this product ensures secure and reliable electrical connections, optimising space utilization on your printed circuit board. Crafted from high-quality materials, it features a natural primary product colour and gold-plated contacts to enhance conductivity and prevent corrosion. The header is suitable for a broad operating temperature range, making it an ideal choice for demanding environments. With support for 15 positions, this connector meets the needs of modern electronic devices, balancing performance with durability and ease of use.
Delivers high electrical performance for reliable signal integrity
Designed for ease of assembly, reducing installation time
Compatible with various PCBs, enhancing versatility
Incorporates a friction lock for secure mating retention
Promotes efficient space management on circuit boards
Engineered to withstand challenging environmental conditions
Utilises a tin plating for increased oxidation resistance
