TE Connectivity AMPMODU Series Vertical Board PCB Header, 9 Contact(s), 2.54 mm Pitch, 1 Row, Shrouded
- RS Stock No.:
- 473-661
- Distrelec Article No.:
- 304-54-152
- Mfr. Part No.:
- 5-104809-8
- Brand:
- TE Connectivity
Subtotal (1 tube of 84 units)*
£187.32
(exc. VAT)
£224.78
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 23 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 + | £187.32 | £2.23 |
*price indicative
- RS Stock No.:
- 473-661
- Distrelec Article No.:
- 304-54-152
- Mfr. Part No.:
- 5-104809-8
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Series | AMPMODU | |
| Product Type | PCB Header | |
| Current | 3A | |
| Pitch | 2.54mm | |
| Housing Material | Thermoplastic | |
| Number of Contacts | 9 | |
| Number of Rows | 1 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Board | |
| Connector System | Wire-to-Board | |
| Contact Plating | Gold | |
| Contact Material | Brass | |
| Row Pitch | 2.54mm | |
| Termination Type | Solder | |
| Minimum Operating Temperature | 65°C | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 3.3mm | |
| Mating Pin Length | 5.84mm | |
| Standards/Approvals | CSA LR7189, UL 94V-0, UL E28476 | |
| Voltage | 60 V | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Series AMPMODU | ||
Product Type PCB Header | ||
Current 3A | ||
Pitch 2.54mm | ||
Housing Material Thermoplastic | ||
Number of Contacts 9 | ||
Number of Rows 1 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Board | ||
Connector System Wire-to-Board | ||
Contact Plating Gold | ||
Contact Material Brass | ||
Row Pitch 2.54mm | ||
Termination Type Solder | ||
Minimum Operating Temperature 65°C | ||
Contact Gender Male | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 3.3mm | ||
Mating Pin Length 5.84mm | ||
Standards/Approvals CSA LR7189, UL 94V-0, UL E28476 | ||
Voltage 60 V | ||
- COO (Country of Origin):
- MX
The TE Connectivity PCB Mount Header is an innovative connector designed for a seamless wire-to-board connection, ensuring robust performance in various applications. With its fully shrouded structure and vertical mount orientation, this connector excels in space-constrained environments while providing reliable electrical connections. Crafted for durability, the component features a gold-plated mating area that enhances conductivity and ensures longevity. Its high-temperature housing rating and extensive operational temperature range make it suitable for demanding conditions. Ideal for signal circuit applications, this connector supports up to 3 A current, promoting efficiency and reliability across a wide array of electronic devices. Upgrade your connectivity solutions with this dependable and versatile component, perfect for both commercial and industrial uses.
Designed for wire-to-board applications, providing secure connections
Fully shrouded header type enhances protection against environmental factors
Optimised for 2.54 mm centreline pitch, fitting standard PCB layouts
Robust contact material and finish ensure excellent mating performance
Compatible with high-temperature applications for versatile usage
Seamless integration into board mount systems for quick installs
Low parasite resistance supports high-frequency signal transfer
Durable plastic housing withstands mechanical stress and environmental exposure
Meets international compliance standards for quality assurance
