TE Connectivity 51790 Series Vertical Board PCB Header, 60 Contact(s), 0.8 mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 469-694
- Mfr. Part No.:
- 5179029-2
- Brand:
- TE Connectivity
Subtotal (1 tube of 48 units)*
£189.36
(exc. VAT)
£227.23
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tube(s) | Per Tube | Per unit* |
|---|---|---|
| 1 + | £189.36 | £3.945 |
*price indicative
- RS Stock No.:
- 469-694
- Mfr. Part No.:
- 5179029-2
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Product Type | PCB Header | |
| Series | 51790 | |
| Pitch | 0.8mm | |
| Current | 0.5A | |
| Number of Contacts | 60 | |
| Housing Material | Matt | |
| Number of Rows | 2 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | Board-to-Board | |
| Mount Type | Board | |
| Contact Plating | Gold | |
| Contact Material | Brass | |
| Row Pitch | 0.8mm | |
| Minimum Operating Temperature | -40°C | |
| Termination Type | Surface Mount | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | 2016, China RoHS 2 Directive MIIT Order No 32, EU ELV Directive 2000/53/EC Compliant, EU RoHS Directive 2011/65/EU Compliant, UL 94V-0 | |
| Voltage | 100 V | |
| Distrelec Product Id | 304-50-957 | |
| Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Product Type PCB Header | ||
Series 51790 | ||
Pitch 0.8mm | ||
Current 0.5A | ||
Number of Contacts 60 | ||
Housing Material Matt | ||
Number of Rows 2 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Connector System Board-to-Board | ||
Mount Type Board | ||
Contact Plating Gold | ||
Contact Material Brass | ||
Row Pitch 0.8mm | ||
Minimum Operating Temperature -40°C | ||
Termination Type Surface Mount | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals 2016, China RoHS 2 Directive MIIT Order No 32, EU ELV Directive 2000/53/EC Compliant, EU RoHS Directive 2011/65/EU Compliant, UL 94V-0 | ||
Voltage 100 V | ||
Distrelec Product Id 304-50-957 | ||
- COO (Country of Origin):
- CN
The TE Connectivity PCB Mount Header is an essential component for those looking to facilitate robust and reliable connections in board-to-board applications. With a vertical configuration and designed for a 60-position setup, this connector allows for exceptional flexibility in layout design. As part of the Free Height series, it offers a low-profile solution that suits various electronic applications where space is at a premium. The fully shrouded design ensures greater contact security, making it suitable for dynamic environments. Additionally, the connector is built to withstand a wide operating temperature range, ensuring dependable performance even in challenging conditions.
Versatile operating temperature range supports diverse applications
Vertical orientation fits a variety of design specifications
Matte housing material reduces glare and improves aesthetic integration
Supports parallel configuration for streamlined assembly
Easy surface mount termination simplifies PCB design
