Rohde & Schwarz Scope Rider Series, 500 MHz Handheld Oscilloscope, 8 Channels - UKAS
- RS Stock No.:
- 179-6298
- Mfr. Part No.:
- RTH1054MSO
- Brand:
- Rohde & Schwarz
Subtotal (1 unit)*
£9,207.57
(exc. VAT)
£11,049.08
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £9,207.57 |
*price indicative
- RS Stock No.:
- 179-6298
- Mfr. Part No.:
- RTH1054MSO
- Brand:
- Rohde & Schwarz
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Rohde & Schwarz | |
| Product Type | Oscilloscope | |
| Bandwidth | 500MHz | |
| Number of Channels | 8 | |
| Oscilloscope Type | Handheld | |
| Memory Depth | 125kpts | |
| Interface Type | CAN, IIC, LIN, RS232, RS422, RS485, SPI, UART, USB | |
| Screen Size | 7 in | |
| Series | Scope Rider | |
| Standards/Approvals | No | |
| Width | 201 mm | |
| Height | 293mm | |
| Depth | 74mm | |
| Power Source | Battery, Mains | |
| Safety Category Level | CAT II, CAT III, CAT IV | |
| Safety Category Voltage | 1000V | |
| Battery Life | 4h | |
| Minimum Time Base | 1ns/div | |
| Rise Time | 700ps | |
| Display Type | TFT LCD | |
| Vertical Resolution | 9 bit | |
| Plug Type | USB | |
| Battery Type | Lithium-ion | |
| Minimum Vertical Sensitivity | 2mV/div | |
| Calibrated | UKAS | |
| Maximum Time Base | 500s/div | |
| Maximum Vertical Sensitivity | 100V/div | |
| Waveform Refresh Rate | 50000per sec | |
| Select all | ||
|---|---|---|
Brand Rohde & Schwarz | ||
Product Type Oscilloscope | ||
Bandwidth 500MHz | ||
Number of Channels 8 | ||
Oscilloscope Type Handheld | ||
Memory Depth 125kpts | ||
Interface Type CAN, IIC, LIN, RS232, RS422, RS485, SPI, UART, USB | ||
Screen Size 7 in | ||
Series Scope Rider | ||
Standards/Approvals No | ||
Width 201 mm | ||
Height 293mm | ||
Depth 74mm | ||
Power Source Battery, Mains | ||
Safety Category Level CAT II, CAT III, CAT IV | ||
Safety Category Voltage 1000V | ||
Battery Life 4h | ||
Minimum Time Base 1ns/div | ||
Rise Time 700ps | ||
Display Type TFT LCD | ||
Vertical Resolution 9 bit | ||
Plug Type USB | ||
Battery Type Lithium-ion | ||
Minimum Vertical Sensitivity 2mV/div | ||
Calibrated UKAS | ||
Maximum Time Base 500s/div | ||
Maximum Vertical Sensitivity 100V/div | ||
Waveform Refresh Rate 50000per sec | ||
- COO (Country of Origin):
- CZ
Rohde & Schwarz RTH100 Series RTH1004 Oscilloscope
The Rohde & Schwarz RTH100 series handheld digital oscilloscope is a portable universal tool for laboratory and field use. It allows a bandwidth of 500MHz, memory depth up to 50MS and sampling rate up to 5GS/s. The input signal voltage required to operate this oscilloscope is 300V. This oscilloscope has LCD TFT, touch display of 7 in with a resolution of 800x480 pixel. The analogue to digital converter resolution is 10 bit. It has four channels. The oscilloscope has isolated channels for power signal measurements up to CAT IV 600V. It performs multiple functions like lab performance oscilloscope, logical and protocol analyser, waveform and pattern generator in one instrument.
Features and Benefits
• Wireless LAN for web-based remote control
• Bandwidth is upgradeable via software keycode
• Includes 8 channel logic probe and micro-test connectors
• Optional software packages available
• Works on Lithium-ion rechargeable battery
• Automatic measurement of multiple parameters
Applications
• Educational institutes
• Used by service technicians
• R&D troubleshooting
• Production testing
• Power electronics
Note
History and segmented memory software is now included in standard RTH configuration for free, offering a saving of up to 18%. This option enables automatic storage of up to 5000 waveforms in a separate history buffer of the oscilloscope. The waveform data can be accessed any time to analyze past acquisitions using all oscilloscope capabilities.
