Fluke 1662 UK FTT Electrical Installation Tester Bundle 10000V With USB

RS Stock No.:: 250-6931
Mfr. Part No.:: 1662 UK FTT
Brand:: Fluke

Fluke 1662 UK FTT Electrical Installation Tester Bundle 10000V With USB

Subtotal (1 unit)*

£1,527.00

(exc. VAT)

£1,832.40

(inc. VAT)

FREE delivery for orders over £60.00

In Stock

1 unit(s) ready to ship

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£1,527.00

*price indicative

RS Stock No.:: 250-6931
Mfr. Part No.:: 1662 UK FTT
Brand:: Fluke

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Fluke
	Product Type	Electrical Installation Tester Bundle
	Loop Impedance Test Type	Phase to Earth, Phase to Neutral
	Automatic RCD Test	Yes
	Model Number	1662 UK FTT
	RCD Ramp Test	Yes
	Non-Tripping	No
	Insulation Test Voltage	10000V
	Maximum Voltage Measurement	660V
	Test Type	Continuity, RCD Test, Patch, Phase Sequence Indication, Miniature GPS
	Interface Type	USB
	Continuity Test Current	1mA
	RCD Test Type	AC
	Width	25cm
	Weight	1.3kg
	Standards/Approvals	ANSI/ISA -s82.02.01 2000 and CAN/CSA c22.2 No. 1010 2nd edition, EN61010-1 Ed 2.0 (2001-02), UL61010
	Length	100.00mm
	Height	12.5mm
	IP Rating	IP40
	Test Standards	EN61557-1 to EN61557-7 Second Edition, EN61557-10 Second Edition
	Battery Type	AA
	Power Source	Battery
	Minimum Continuity Resistance	20Ω
	Safety Category Level	CAT III, CAT IV
	Safety Category Voltage	500V
	Maximum Continuity Resistance	2000Ω

	Select all
	Brand Fluke
	Product Type Electrical Installation Tester Bundle
	Loop Impedance Test Type Phase to Earth, Phase to Neutral
	Automatic RCD Test Yes
	Model Number 1662 UK FTT
	RCD Ramp Test Yes
	Non-Tripping No
	Insulation Test Voltage 10000V
	Maximum Voltage Measurement 660V
	Test Type Continuity, RCD Test, Patch, Phase Sequence Indication, Miniature GPS
	Interface Type USB
	Continuity Test Current 1mA
	RCD Test Type AC
	Width 25cm
	Weight 1.3kg
	Standards/Approvals ANSI/ISA -s82.02.01 2000 and CAN/CSA c22.2 No. 1010 2nd edition, EN61010-1 Ed 2.0 (2001-02), UL61010
	Length 100.00mm
	Height 12.5mm
	IP Rating IP40
	Test Standards EN61557-1 to EN61557-7 Second Edition, EN61557-10 Second Edition
	Battery Type AA
	Power Source Battery
	Minimum Continuity Resistance 20Ω
	Safety Category Level CAT III, CAT IV
	Safety Category Voltage 500V
	Maximum Continuity Resistance 2000Ω

COO (Country of Origin):: GB

Fluke Electrical Installation Tester Bundle, 500V Safety Category Voltage, 1.3kg Weight - 1662 UK FTT

This electrical installation tester bundle is a handheld tester designed for verifying electrical circuits and protective devices in installations. It operates from battery power and connects to external devices via USB, providing a compact, portable solution for routine verification of continuity, insulation and RCD performance within installation environments.

Features and Benefits:

• Insulation testing to 10000V for high-voltage withstand verification
• Continuity at 1mA to detect conductor integrity up to 2000Ω
• RCD AC automatic ramp test for dynamic trip assessment
• Loop impedance measurements phase to earth and phase to neutral
• Safety rating CAT III and CAT IV for 500V site testing
• IP40 ingress protection for indoor workshop and site use

Applications

• Suitable for verifying protective device operation during commissioning
• Used for insulation resistance checks on high-voltage components
• Ideal for measuring loop impedance in distribution boards
• Can be used for continuity checks on lighting and sockets
• Used with onsite reporting via USB connection to a computer

What battery type does it use and how is it replaced?

It uses standard AA batteries that are accessed via a rear compartment for quick field replacement.

Which standards govern its test routines and accuracy?

Test methods conform to EN 61557 parts 1-7 and part 10, second edition, for installation testing.

Does it support phase sequence or polarity indication?

It provides phase sequence indication to confirm correct phase rotation during installation checks.

What protection classifications apply to working voltage and environment?

The instrument is rated for 500V in CAT III and CAT IV environments and has an IP40 enclosure rating.

Supplied with

1662 Multifunction Installation Tester
6x AA (IEC LR6) cell batteries
C1600 hard carrying case
Zero adapter
Heavy duty mains cord
STD standard test lead set
Padded carrying and waist strap
Quick reference guide
TP165X remote control probe and lead
IR189USB cable
TruTest Data Management Software
