Infineon BSZ Type N-Channel MOSFET, 40 A, 100 V N, 8-Pin TSDSON-8 FL BSZ0804LSATMA1

RS Stock No.:: 234-6993
Mfr. Part No.:: BSZ0804LSATMA1
Brand:: Infineon

Infineon BSZ Type N-Channel MOSFET, 40 A, 100 V N, 8-Pin TSDSON-8 FL BSZ0804LSATMA1

Bulk discount available

Subtotal (1 pack of 5 units)*

£5.93

(exc. VAT)

£7.115

(inc. VAT)

FREE delivery for orders over £50.00

Last RS stock

Final 1,535 unit(s), ready to ship

Units	Per unit	Per Pack*
5 - 45	£1.186	£5.93
50 - 120	£1.044	£5.22
125 - 245	£0.984	£4.92
250 - 495	£0.914	£4.57
500 +	£0.842	£4.21

*price indicative

RS Stock No.:: 234-6993
Mfr. Part No.:: BSZ0804LSATMA1
Brand:: Infineon

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Infineon
	Product Type	MOSFET
	Channel Type	Type N
	Maximum Continuous Drain Current Id	40A
	Maximum Drain Source Voltage Vds	100V
	Series	BSZ
	Package Type	TSDSON-8 FL
	Mount Type	Surface
	Pin Count	8
	Maximum Drain Source Resistance Rds	13.5mΩ
	Channel Mode	N
	Typical Gate Charge Qg @ Vgs	12nC
	Minimum Operating Temperature	-55°C
	Maximum Gate Source Voltage Vgs	20 V
	Forward Voltage Vf	1.2V
	Maximum Power Dissipation Pd	69W
	Maximum Operating Temperature	150°C
	Standards/Approvals	No
	Length	5.35mm
	Height	1.2mm
	Width	6.1 mm
	Automotive Standard	No

	Select all
	Brand Infineon
	Product Type MOSFET
	Channel Type Type N
	Maximum Continuous Drain Current Id 40A
	Maximum Drain Source Voltage Vds 100V
	Series BSZ
	Package Type TSDSON-8 FL
	Mount Type Surface
	Pin Count 8
	Maximum Drain Source Resistance Rds 13.5mΩ
	Channel Mode N
	Typical Gate Charge Qg @ Vgs 12nC
	Minimum Operating Temperature -55°C
	Maximum Gate Source Voltage Vgs 20 V
	Forward Voltage Vf 1.2V
	Maximum Power Dissipation Pd 69W
	Maximum Operating Temperature 150°C
	Standards/Approvals No
	Length 5.35mm
	Height 1.2mm
	Width 6.1 mm
	Automotive Standard No

The Infineon OptiMOS™ PD N-channel power MOSFET targets USB-PD and adapter applications. The product offers fast ramp-up and optimized lead times. OptiMOS™ low-voltage MOSFETs for power delivery enable designs with less parts leading to BOM cost reduction and features quality products in compact, lightweight packages. It has 40A maximum continuous drain current and 100V maximum drain source voltage It is Ideal for high-frequency switching and optimized for chargers.

Logic level availability

Low on-state resistance RDS(on)

Low gate, output and reverse recovery charge

Excellent thermal behaviour

100% avalanche tested

Pb-free lead plating

Halogen-freeaccordingtoIEC61249-2-21

RoHS compliant

Available in 2 small standard packages
