ROHM BM2 MOSFET, 9 A, 800 V, 3-Pin DIP7AK BM2P061HK-LBZ
- RS Stock No.:
- 264-856
- Mfr. Part No.:
- BM2P061HK-LBZ
- Brand:
- ROHM
Bulk discount available
Subtotal (1 pack of 5 units)*
£11.70
(exc. VAT)
£14.05
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 100 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
5 - 45 | £2.34 | £11.70 |
50 - 95 | £2.222 | £11.11 |
100 + | £2.06 | £10.30 |
*price indicative
- RS Stock No.:
- 264-856
- Mfr. Part No.:
- BM2P061HK-LBZ
- Brand:
- ROHM
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | ROHM | |
Maximum Continuous Drain Current | 9 A | |
Maximum Drain Source Voltage | 800 V | |
Series | BM2 | |
Package Type | DIP7AK | |
Mounting Type | Through Hole | |
Pin Count | 3 | |
Select all | ||
---|---|---|
Brand ROHM | ||
Maximum Continuous Drain Current 9 A | ||
Maximum Drain Source Voltage 800 V | ||
Series BM2 | ||
Package Type DIP7AK | ||
Mounting Type Through Hole | ||
Pin Count 3 | ||
The ROHM PWM Type DC or DC Converter IC Integrated Switching MOSFET provides an optimum system for various electrical product. It supports both isolated and non-isolated devices, enabling simpler design of various types of low power consumption electrical converters. This series also has a built-in starter circuit that can withstand up to 800 V, which contributes to low power consumption. Since current mode control is utilized, current is restricted in each cycle and excellent performance is demonstrated in bandwidth and transient response. Switching frequency is fixed at 65 kHz, 100 kHz or 130 kHz. At light load, the switching frequency is reduced and high efficiency is achieved. A frequency hopping function is also built-in, which contributes to low EMI. In addition, this product has a built-in Super Junction MOSFET which has a withstand voltage of 800 V.
Long Time Support Product for Industrial Applications
Over Current Limiter with AC Voltage Correction
PWM Current Mode Control
Built-in Frequency Hopping Function
Burst Operation at Light Load
Frequency Reduction Function
Highly Precise AC Over Voltage Protection
Over Current Limiter with AC Voltage Correction
PWM Current Mode Control
Built-in Frequency Hopping Function
Burst Operation at Light Load
Frequency Reduction Function
Highly Precise AC Over Voltage Protection
