Microchip DSPIC30F3014-30I/PT, 16bit dsPIC Microcontroller, dsPIC30F, 25MHz, 24 kB Flash, 40-Pin TQFP

RS Stock No.:: 197-6092
Mfr. Part No.:: DSPIC30F3014-30I/PT
Brand:: Microchip

Microchip DSPIC30F3014-30I/PT, 16bit dsPIC Microcontroller, dsPIC30F, 25MHz, 24 kB Flash, 40-Pin TQFP

Bulk discount available

Subtotal (1 pack of 2 units)**

£10.20

(exc. VAT)

£12.24

(inc. VAT)

Available to back order for despatch 12/05/2025*

* Delivery dates may change based on your chosen quantity and delivery address.

FREE delivery for orders over £50.00

Units	Per unit	Per Pack**
2 - 8	£5.10	£10.20
10 - 18	£4.955	£9.91
20 - 48	£4.835	£9.67
50 - 98	£4.705	£9.41
100 +	£4.59	£9.18

**price indicative

RS Stock No.:: 197-6092
Mfr. Part No.:: DSPIC30F3014-30I/PT
Brand:: Microchip

Datasheet - dsPIC30F3014

Attribute	Value
Family Name	dsPIC30F
Package Type	TQFP
Mounting Type	Surface Mount
Pin Count	40
Device Core	dsPIC
Data Bus Width	16bit
Program Memory Size	24 kB
Maximum Frequency	25MHz
RAM Size	2 kB
USB Channels	0
Number of PWM Units	2 x 16 bit
Number of SPI Channels	1
Number of USART Channels	0
Typical Operating Supply Voltage	2.5 → 5.5 V
Number of I2C Channels	1
Number of UART Channels	2
Number of CAN Channels	0
Program Memory Type	Flash
Dimensions	10 x 10 x 1mm
Height	1mm
Minimum Operating Temperature	-40 °C
Instruction Set Architecture	RISC
Number of ADC Units	1
ADCs	13 x 12 bit
Length	10mm
Number of PCI Channels	0
Number of Ethernet Channels	0
Maximum Operating Temperature	+85 °C
Pulse Width Modulation	3 (16 bit)
Number of LIN Channels	0
Width	10mm
Maximum Number of Ethernet Channels	0

Microchip DSPIC30F3014-30I/PT, 16bit dsPIC Microcontroller, dsPIC30F, 25MHz, 24 kB Flash, 40-Pin TQFP
