TE Connectivity 2108824-1 Square Omnidirectional GPS Antenna, GPS

View all GPS Antennas
Bulk discount available

Subtotal (1 pack of 5 units)*

£9.58

(exc. VAT)

£11.495

(inc. VAT)

Add to Basket
Select or type quantity
Last RS stock
  • Final 3,385 unit(s), ready to ship
Units
Per unit
Per Pack*
5 - 45£1.916£9.58
50 - 95£1.804£9.02
100 - 495£1.532£7.66
500 - 995£1.258£6.29
1000 +£1.076£5.38

*price indicative

Packaging Options:
RS Stock No.:
235-1395
Mfr. Part No.:
2108824-1
Brand:
TE Connectivity
Find similar products by selecting one or more attributes.
Select all

Brand

TE Connectivity

Internal/External

Internal

Antenna Physical Form

Square

Antenna Mounting Type

SMD

Includes Lead

No

Antenna Directivity

Omnidirectional

RF Protocols

GPS

Gain

2.9dBi

Series

GNSS

COO (Country of Origin):
KR
The TE Connectivity Embedded Ceramic Chip Antenna is linear polarization antenna which uses L1+G1 bands for GNSS protocol. It has dimension of 10.0 mm x 3.0 mm x 1.5 mm. The following data is based on 80 x 40 mm ground size.

Antenna connection type surface mount (SMT)
Antenna style embedded
Impedance 50 Ω
Active antenna no
Gain (Max) 2.9 dB
Polarization linear
Mounts to printed circuit board
Application by Region GNSS – Global – 1559 – 1610 MHz, Wireless Standard=L1/GPS Glonass Galileo
Wireless application GNSS
