Aim-TTi TG315 Function Generator, 0.03Hz Min, 3MHz Max - With RS Calibration

RS Stock No.:: 467-7418
Mfr. Part No.:: TG315
Brand:: Aim-TTi

Aim-TTi TG315 Function Generator, 0.03Hz Min, 3MHz Max - With RS Calibration

Currently unavailable

Sorry, we don't know when this will be back in stock.

RS Stock No.:: 467-7418
Mfr. Part No.:: TG315
Brand:: Aim-TTi

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Aim-TTi
	Maximum Frequency Range Sinewave	3MHz
	Calibrated	RSCAL
	Maximum Frequency Range Square Pulse and Arbitrary Waveform	3MHz
	Series	TG300
	Output Impedance	50 Ω, 600 Ω
	Minimum Frequency Range Sinewave	0.03Hz
	Minimum Frequency Range Square Pulse and Arbitrary Waveform	0.03 Hz
	Time Base Accuracy	±10ppm
	Digital Frequency	Yes
	Maximum Frequency Range Triangle/Saw	3MHz
	Minimum Frequency Range Triangle/Saw	0.03Hz
	Frequency Range Square Pulse and Arbitrary Waveform	0.03 Hz → 3 MHz
	Plug Type	Type C - European Plug, Type G - British 3-pin
	Dimensions	235 x 260 x 88mm
	Model Number	TG315
	Output Amplitude	20V Pk-Pk
	Minimum Operating Temperature	+5°C
	Height	88mm
	Length	235mm
	Input Impedance	10 kΩ
	Attenuation	-60 dB, -40 dB, -20 dB, 0 dB
	Maximum Operating Temperature	+40°C
	CMOS Output Level	0 → 5V
	TTL Output Level	0 → 5V
	Digital Amplitude and Offset	Yes
	Width	260mm
	Weight	1.9kg

	Select all
	Brand Aim-TTi
	Maximum Frequency Range Sinewave 3MHz
	Calibrated RSCAL
	Maximum Frequency Range Square Pulse and Arbitrary Waveform 3MHz
	Series TG300
	Output Impedance 50 Ω, 600 Ω
	Minimum Frequency Range Sinewave 0.03Hz
	Minimum Frequency Range Square Pulse and Arbitrary Waveform 0.03 Hz
	Time Base Accuracy ±10ppm
	Digital Frequency Yes
	Maximum Frequency Range Triangle/Saw 3MHz
	Minimum Frequency Range Triangle/Saw 0.03Hz
	Frequency Range Square Pulse and Arbitrary Waveform 0.03 Hz → 3 MHz
	Plug Type Type C - European Plug, Type G - British 3-pin
	Dimensions 235 x 260 x 88mm
	Model Number TG315
	Output Amplitude 20V Pk-Pk
	Minimum Operating Temperature +5°C
	Height 88mm
	Length 235mm
	Input Impedance 10 kΩ
	Attenuation -60 dB, -40 dB, -20 dB, 0 dB
	Maximum Operating Temperature +40°C
	CMOS Output Level 0 → 5V
	TTL Output Level 0 → 5V
	Digital Amplitude and Offset Yes
	Width 260mm
	Weight 1.9kg

RoHS Status: Exempt

COO (Country of Origin):: GB

Aim-TTi TG300 Series Function Generator, 0.03 Hz to 3 MHz Frequency Range, 0 to 5 V TTL Output Level - TG315

This function generator from Aim-TTi provides a wide frequency range of 0.03Hz to 3MHz with precise control and versatile functionality. Ideal for various applications across the industries, it offers high-frequency outputs and attenuator options for accurate testing and waveform generation.

Features & Benefits

• Covering a wide frequency range from 0.03Hz to 3MHz, this device caters to diverse testing needs

• It offers multiple attenuation levels (-60 dB, -40 dB, -20 dB, 0 dB) to accommodate various signal amplitudes

• The device features digital frequency control, enabling precise adjustments for accurate waveform generation

• With dimensions of 235 x 260 x 88 mm, it is Compact and portable, suitable for both bench and rack use

• Providing outputs for main 50 Ohm, 600 Ohm, external TTL, and CMOS, it caters to different load requirements, ensuring versatility

Applications

• Ideal for signal analysis, frequency response testing, and waveform generation

• Useful for developing and testing electronic circuits with varying signal frequencies

• Suitable for laboratories, educational institutions for teaching electronics concepts effectively

Can it generate signals in a wide frequency range?

Yes, the function generator covers a frequency range from 0.03Hz to 3MHz for versatile testing applications.

Is it portable for easy bench use?

The Compact design and portable nature make it suitable for both benchtop and rack installations.

Will it provide precise control over signal amplitudes?

With attenuation levels ranging from -60 dB to 0 dB, the generator ensures accurate signal amplitudes for testing.

Does it offer different output impedance options?

Yes, the generator provides options for 50 Ohm, 600 Ohm, and auxiliary outputs to cater to various load requirements.

Can it be used for educational purposes?

The function generator is suitable for educational institutions, laboratories, and electronics training due to its versatile features and ease of use.
