Molex, 52806-0510 1 mm Pitch 5 Way Vertical FPC Connector
- RS Stock No.:
- 469-909
- Distrelec Article No.:
- 304-62-597
- Mfr. Part No.:
- 52806-0510
- Brand:
- Molex
Subtotal (1 tray of 1200 units)*
£147.02
(exc. VAT)
£176.42
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 16 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tray(s) | Per Tray | Per unit* |
|---|---|---|
| 1 + | £147.02 | £0.123 |
*price indicative
- RS Stock No.:
- 469-909
- Distrelec Article No.:
- 304-62-597
- Mfr. Part No.:
- 52806-0510
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Product Type | FPC Connector | |
| Number of Contacts | 5 | |
| Sub Type | Easy-On | |
| Contact Material | Phosphor Bronze | |
| Current | 0.5A | |
| Pitch | 1mm | |
| Mount Type | Surface Mount | |
| Orientation | Vertical | |
| Insertion Force | Non-ZIF | |
| Voltage | 5 V | |
| Minimum Operating Temperature | -20°C | |
| Series | 52806-0510 | |
| Maximum Operating Temperature | 80°C | |
| Standards/Approvals | 94V-0, UL E29179 | |
| Contact Plating | Tin | |
| Housing Material | High Temperature Thermoplastic | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Product Type FPC Connector | ||
Number of Contacts 5 | ||
Sub Type Easy-On | ||
Contact Material Phosphor Bronze | ||
Current 0.5A | ||
Pitch 1mm | ||
Mount Type Surface Mount | ||
Orientation Vertical | ||
Insertion Force Non-ZIF | ||
Voltage 5 V | ||
Minimum Operating Temperature -20°C | ||
Series 52806-0510 | ||
Maximum Operating Temperature 80°C | ||
Standards/Approvals 94V-0, UL E29179 | ||
Contact Plating Tin | ||
Housing Material High Temperature Thermoplastic | ||
- COO (Country of Origin):
- MY
The TE Connectivity 1.00mm Pitch Easy-On FFC/FPC Connector stands as a robust choice for designers seeking reliable connectivity solutions. Engineered for vertical surface mount applications, this connector fuses practicality with advanced features, making it ideal for non-ZIF configurations. Its kinked PC tails ensure secure connections while accommodating five circuits, showcasing a thoughtful design that prioritises performance. With a focus on environmental compliance, this connector meets various industry standards, solidifying its place in modern electronic assemblies. Its efficient packaging and precision manufacturing translate to ease of use and installation, complementing the demands of contemporary design in FFC/FPC applications.
Offers compatibility with non-ZIF configurations for versatile applications
Designed to support multiple circuits, enhancing connectivity options
Constructed from high-temperature thermoplastic to withstand tough conditions
Durable construction allows for up to 10 mating cycles, ensuring longevity
Natural resin colour integrates seamlessly into various design aesthetics
Vertical orientation simplifies PCB layout and optimises space usage
Tailored for through-hole mounting, providing stability and reliability
