Finder 39 Series Interface Relay, DIN Rail, 24V ac/dc Coil, SPDT, 11mA
- RS Stock No.:
- 819-8859
- Distrelec Article No.:
- 301-05-986
- Mfr. Part No.:
- 39.61.0.024.0060
- Brand:
- Finder
Bulk discount available
Subtotal (1 unit)*
£19.51
(exc. VAT)
£23.41
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 100 unit(s) shipping from 07 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £19.51 |
| 5 - 9 | £18.90 |
| 10 + | £18.09 |
*price indicative
- RS Stock No.:
- 819-8859
- Distrelec Article No.:
- 301-05-986
- Mfr. Part No.:
- 39.61.0.024.0060
- Brand:
- Finder
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Finder | |
| Product Type | Interface Relay | |
| Coil Voltage | 24V ac/dc | |
| Contact Configuration | SPDT | |
| Mount Type | DIN Rail | |
| Series | 39 | |
| Terminal Type | Push-in | |
| Switching Current | 6A | |
| Switching DC Voltage | 24V dc | |
| Switching AC Voltage | 250V ac | |
| Coil Current | 11mA | |
| Minimum Operating Temperature | -40°C | |
| Contact Material | Silver Alloy | |
| Maximum Operating Temperature | 70°C | |
| Width | 90.7mm | |
| Standards/Approvals | EAC, CE | |
| Length | 6.2mm | |
| Height | 94.3mm | |
| Select all | ||
|---|---|---|
Brand Finder | ||
Product Type Interface Relay | ||
Coil Voltage 24V ac/dc | ||
Contact Configuration SPDT | ||
Mount Type DIN Rail | ||
Series 39 | ||
Terminal Type Push-in | ||
Switching Current 6A | ||
Switching DC Voltage 24V dc | ||
Switching AC Voltage 250V ac | ||
Coil Current 11mA | ||
Minimum Operating Temperature -40°C | ||
Contact Material Silver Alloy | ||
Maximum Operating Temperature 70°C | ||
Width 90.7mm | ||
Standards/Approvals EAC, CE | ||
Length 6.2mm | ||
Height 94.3mm | ||
- COO (Country of Origin):
- IT
Finder Series 39 Interface Relay, SPDT Contact Configuration, Push-in Terminal - 39.61.0.024.0060
This interface relay facilitates efficient control in automation systems. It boasts a compact SPDT configuration with dimensions of 6.2x90.7x94.3mm, providing a space-saving solution for various applications. With a coil voltage of 24V AC/DC, it ensures reliable switching in both AC and DC environments and operates effectively in temperatures ranging from -40 to +70°C.
Features & Benefits
• Push-in terminal for secure connections
• Compact design optimises mounting space
• Dual screw head terminals enhance usability
• High switching voltage capability supports different applications
• Integrated coil protection circuit for improved reliability
• Compatible with standard 35mm rail mounting
Applications
• Used in control panels for relay operations
• Employed in traffic light control systems
• Utilised in labelling and bottling machinery
• Implemented in carousel warehouses and hoisting operations
• Ideal for automation systems requiring reliable interfacing
Can it operate in adverse temperature conditions?
Yes, it functions effectively from -40°C to +70°C.
Is it easy to install in existing systems?
Yes, the push-in terminals simplify the installation process.
Can it handle high voltage switching applications?
Yes, it supports switching voltages up to 250V/400V AC.
Does it come with built-in protection features?
Yes, it includes an integral coil protection circuit for safety.
