Finder 4C Series Interface Relay, DIN Rail Mount, 12V ac Coil, SPDT, 1-Pole, 10A Load
- RS Stock No.:
- 123-2824
- Mfr. Part No.:
- 4C.P1.8.012.0060SPA
- Brand:
- Finder
Subtotal (1 unit)*
£20.72
(exc. VAT)
£24.86
(inc. VAT)
FREE delivery for orders over £50.00
- 2 unit(s) ready to ship
- Plus 999,999,997 unit(s) shipping from 18 October 2025
Units | Per unit |
|---|---|
| 1 + | £20.72 |
*price indicative
- RS Stock No.:
- 123-2824
- Mfr. Part No.:
- 4C.P1.8.012.0060SPA
- Brand:
- Finder
Select all | Attribute | Value |
|---|---|---|
| Brand | Finder | |
| Coil Voltage | 12V ac | |
| Contact Configuration | SPDT | |
| Mounting Type | DIN Rail | |
| Series | 4C Series | |
| Number of Poles | 1 | |
| Load Current Rating | 10A | |
| Maximum Input Voltage | 440V ac | |
| Minimum Input Voltage | 250V ac | |
| Terminal Type | Push In | |
| Switching Voltage | 250 V ac → 440V ac | |
| Depth | 66.8mm | |
| Height | 95.5mm | |
| Length | 15.8mm | |
| Contact Material | Silver Alloy | |
| Input Current | 90mA | |
| Input Resistance | 80Ω | |
| Special Features | AC Coils or DC Coils, Identification Label, Supply Status Indication & Coil Suppression Module as Standard | |
| Standards Met | CE, CSA, CULus, EAC, GOST, IMQ, VDE | |
| Relay Switching Classification | General Purpose Relay | |
| Maximum Operating Temperature | +50°C | |
| Minimum Operating Temperature | -40°C | |
| Turn Off Time | (dc) 12 ms, (ac) 5ms | |
| Operating Temperature Range | -40 → +50°C | |
| Dimensions | 15.8 x 66.8 x 95.5mm | |
| Turn On Time | (ac) 15 ms, (dc) 15ms | |
Select all | ||
|---|---|---|
Brand Finder | ||
Coil Voltage 12V ac | ||
Contact Configuration SPDT | ||
Mounting Type DIN Rail | ||
Series 4C Series | ||
Number of Poles 1 | ||
Load Current Rating 10A | ||
Maximum Input Voltage 440V ac | ||
Minimum Input Voltage 250V ac | ||
Terminal Type Push In | ||
Switching Voltage 250 V ac → 440V ac | ||
Depth 66.8mm | ||
Height 95.5mm | ||
Length 15.8mm | ||
Contact Material Silver Alloy | ||
Input Current 90mA | ||
Input Resistance 80Ω | ||
Special Features AC Coils or DC Coils, Identification Label, Supply Status Indication & Coil Suppression Module as Standard | ||
Standards Met CE, CSA, CULus, EAC, GOST, IMQ, VDE | ||
Relay Switching Classification General Purpose Relay | ||
Maximum Operating Temperature +50°C | ||
Minimum Operating Temperature -40°C | ||
Turn Off Time (dc) 12 ms, (ac) 5ms | ||
Operating Temperature Range -40 → +50°C | ||
Dimensions 15.8 x 66.8 x 95.5mm | ||
Turn On Time (ac) 15 ms, (dc) 15ms | ||
