TDK-Lambda PXC-M03 DC/DC Converter, 15V dc/ 0.1 A, 36V dc Input, 9V dc Input 3 W, PCB, 105 °C Max Temp -40 °C Min Temp,

View all DC-DC Converters
Bulk discount available

Subtotal (1 tube of 10 units)*

£408.35

(exc. VAT)

£490.02

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 03 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Tube(s)
Per Tube
Per unit*
1 - 4£408.35£40.835
5 - 9£396.09£39.609
10 - 24£383.84£38.384
25 - 49£371.60£37.16
50 +£359.34£35.934

*price indicative

RS Stock No.:
204-0504
Mfr. Part No.:
PXC-M03-24WD15
Brand:
TDK-Lambda
Find similar products by selecting one or more attributes.
Select all

Brand

TDK-Lambda

Output Voltage 1

15V dc

Product Type

DC/DC Converter

Maximum Input Voltage

36V dc

Minimum Input Voltage

9V dc

Output Current 1

0.1A

Output Current 2

-0.1A

Output Voltage 2

-15V dc

Mount Type

PCB

Input Ratio

4:1

Number of Outputs

2

MTBF

6444000h

Output Voltage Adjustment Range

±10 %

Ripple and Noise

40mV

Number of Pins

8

Isolation Voltage

5kV

Maximum Output Power

3W

Package Type

DIP

Depth

10.2mm

Length

31.8mm

Width

20.3mm

Series

PXC-M03

Standards/Approvals

No

Weight

14g

Maximum Operating Temperature

105°C

Efficiency

0.86%

Minimum Operating Temperature

-40°C

COO (Country of Origin):
TW
The TDK-Lambda PXC-M03 series is a range of reliable and robust range of medically certified low-power DC-DC converters. The PXC-M series offers a compact & sturdy conversion solution. Supplied in the industry-standard DIP-24 PCB mounting footprint, and supporting up to 5000 V ac insulated input to output. Outputs can be both single & dual output depending on the application requirement. They are also suitable for a wide variety of applications within the medical & communications industries.

https://product.tdk.com/info/en/catalog/datasheets/pxc-m3_e.pdf
