TDK-Lambda PXC-M03W DC-DC Converter, 3.3V dc/ 1A Output, 18 → 75 V dc Input, 3W, PCB Mount, +94°C Max Temp -40°C
- RS Stock No.:
- 173-9165
- Mfr. Part No.:
- PXC-M03-48WS3P3
- Brand:
- TDK-Lambda
Available to back order for despatch 03/09/2024
Added
Price 1 Tube of 10
£401.20
(exc. VAT)
£481.44
(inc. VAT)
| Tube(s) | Per Tube | Per unit* |
| 1 - 4 | £401.20 | £40.12 |
| 5 - 9 | £389.16 | £38.916 |
| 10 - 24 | £377.13 | £37.713 |
| 25 - 49 | £365.09 | £36.509 |
| 50 + | £353.06 | £35.306 |
| *price indicative | ||
- RS Stock No.:
- 173-9165
- Mfr. Part No.:
- PXC-M03-48WS3P3
- Brand:
- TDK-Lambda
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
TDK-Lambda Isolated DC-DC Converter, PXC-M03 Series
Reliable & robust range of medically certified low-power DC-DC converters from Lambda-TDK. The PXC-M series offers a compact & sturdy conversion solution. Supplied in the industry-standard DIP-24 PCB mounting footprint, and supporting up to 5000 V ac insulated input to output. Outputs can be both single & dual output depending on the application requirement.
Suitable for a wide variety of applications within the medical & communications industries.
Suitable for a wide variety of applications within the medical & communications industries.
PCB mounting
Convection cooling technology, meaning the converter does not require a fan for heat dissipation
Long lifespan with a mean time before failure (MTBF) rating of 644,400 hours
Comes with industry standard safety features, such as over voltage, over temperature & short circuit protection
Convection cooling technology, meaning the converter does not require a fan for heat dissipation
Long lifespan with a mean time before failure (MTBF) rating of 644,400 hours
Comes with industry standard safety features, such as over voltage, over temperature & short circuit protection
Standards
MIL-STD-810F, EN55011, EN55022, EN61000 -4-2/3/4/5/6, IEC60601-1, ANSI/AAMI ES60601-1, EN60601-1 & CE approvals.
TDK-Lambda Isolated DC/DC Converters, PXC-M Series
Specifications
Attribute | Value |
|---|---|
| Output Voltage | 3.3V dc |
| Input Voltage Range | 18 → 75 V dc |
| Power Rating | 3W |
| Input Voltage Nominal | 48 V dc |
| Output Current | 1A |
| Mounting Type | PCB Mount |
| Isolated | Yes |
| Number of Outputs | 1 |
| Output Voltage Adjustment Range | ±10% |
| Isolation Voltage | 5kV ac |
| Depth | 10.2mm |
| Width | 20.3mm |
| Length | 31.8mm |
| Railway Approved | No |
| Series | PXC-M03W |
| Standards Met | 60601-1 Approval, ANSI/AAMI ES60601-1, CE Mark, Class A and FCC part 18, Easier System Approval, EN55011, EN55022, EN60601-1, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, IEC60601-1, MIL-STD-810F |
| Efficiency | 81% |
| Medical Approved | Yes |
| Minimum Temperature | -40°C |
| Maximum Temperature | +94°C |
