TDK-Lambda PXC-M03W DC/DC Converter, 12V dc, -12 V dc/ 125 mA, 24V dc Input, 24V dc Input 3 W, PCB, 94 °C Max Temp -40

View all DC-DC Converters
Bulk discount available

Subtotal (1 tube of 10 units)*

£508.42

(exc. VAT)

£610.10

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 04 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Tube(s)
Per Tube
Per unit*
1 - 4£508.42£50.842
5 - 9£493.16£49.316
10 - 24£477.92£47.792
25 - 49£462.66£46.266
50 +£447.41£44.741

*price indicative

RS Stock No.:
173-9154
Mfr. Part No.:
PXC-M03-24WD12
Brand:
TDK-Lambda
Find similar products by selecting one or more attributes.
Select all

Brand

TDK-Lambda

Product Type

DC/DC Converter

Output Voltage 1

12, -12V dc

Minimum Input Voltage

24V dc

Maximum Input Voltage

24V dc

Output Current 1

125mA

Mount Type

PCB

Number of Outputs

2

MTBF

644400h

Output Voltage Adjustment Range

±13.2 V dc

Ripple and Noise

40mV

Isolation Voltage

5kV ac

Maximum Output Power

3W

Package Type

DIP

Standards/Approvals

Class A and FCC part 18, EN55011, EN55022, EN60601-1, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, IEC60601-1, MIL-STD-810F, 60601-1, ANSI/AAMI ES60601-1, CE

Depth

10.2mm

Width

20.3mm

Length

31.8mm

Weight

14g

Series

PXC-M03W

Efficiency

87%

Maximum Operating Temperature

94°C

Minimum Operating Temperature

-40°C

COO (Country of Origin):
TW

TDK-Lambda Isolated DC-DC Converter, PXC-M03 Series


Reliable & robust range of medically certified low-power DC-DC converters from Lambda-TDK. The PXC-M series offers a compact & sturdy conversion solution. Supplied in the industry-standard DIP-24 PCB mounting footprint, and supporting up to 5000 V ac insulated input to output. Outputs can be both single & dual output depending on the application requirement.

Suitable for a wide variety of applications within the medical & communications industries.

PCB mounting

Convection cooling technology, meaning the converter does not require a fan for heat dissipation

Long lifespan with a mean time before failure (MTBF) rating of 644,400 hours

Comes with industry standard safety features, such as over voltage, over temperature & short circuit protection

TDK-Lambda Isolated DC/DC Converters, PXC-M Series


Standards

MIL-STD-810F, EN55011, EN55022, EN61000 -4-2/3/4/5/6, IEC60601-1, ANSI/AAMI ES60601-1, EN60601-1 & CE approvals.
