TDK-Lambda PXC-M03W DC-DC Converter, 24V dc/ 125mA Output, 18 → 75 V dc Input, 3W, PCB Mount, +94°C Max Temp

RS Stock No.:: 173-9176
Mfr. Part No.:: PXC-M03-48WS24
Brand:: TDK-Lambda

TDK-Lambda PXC-M03W DC-DC Converter, 24V dc/ 125mA Output, 18 → 75 V dc Input, 3W, PCB Mount, +94°C Max Temp

Available to back order for despatch 13/11/2024

Price 1 Tube of 10

£466.04

(exc. VAT)

£559.25

(inc. VAT)

Tube(s)	Per Tube	Per unit*
1 - 4	£466.04	£46.604
5 - 9	£452.06	£45.206
10 - 24	£438.08	£43.808
25 - 49	£424.10	£42.41
50 +	£410.12	£41.012

*price indicative

RS Stock No.:: 173-9176
Mfr. Part No.:: PXC-M03-48WS24
Brand:: TDK-Lambda

TDK-Lambda PXC-M Series Product Preview

Attribute	Value
Output Voltage	24V dc
Input Voltage Range	18 → 75 V dc
Power Rating	3W
Input Voltage Nominal	48 V dc
Output Current	125mA
Mounting Type	PCB Mount
Isolated	Yes
Number of Outputs	1
Output Voltage Adjustment Range	-10/+20%
Isolation Voltage	5kV ac
Depth	10.2mm
Width	20.3mm
Length	31.8mm
Railway Approved	No
Series	PXC-M03W
Medical Approved	Yes
Efficiency	86.5%
Maximum Temperature	+94°C
Standards Met	60601-1 Approval, ANSI/AAMI ES60601-1, CE Mark, Class A and FCC part 18, Easier System Approval, EN55011, EN55022, EN60601-1, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, IEC60601-1, MIL-STD-810F
Minimum Temperature	-40°C

TDK-Lambda PXC-M03W DC-DC Converter, 24V dc/ 125mA Output, 18 → 75 V dc Input, 3W, PCB Mount, +94°C Max Temp

TDK-Lambda Isolated DC-DC Converter, PXC-M03 Series
