TE Connectivity AMPLIMITE 37 Way Panel Mount D-sub Connector Plug, 2.77mm Pitch, with Screw Holes
- RS Stock No.:
- 474-633
- Mfr. Part No.:
- 205168-1
- Brand:
- TE Connectivity
Subtotal (1 reel of 10 units)*
£145.63
(exc. VAT)
£174.76
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per unit* |
---|---|---|
1 + | £145.63 | £14.563 |
*price indicative
- RS Stock No.:
- 474-633
- Mfr. Part No.:
- 205168-1
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TE Connectivity | |
Number of Contacts | 37 | |
Gender | Male | |
Body Orientation | Straight | |
Mounting Type | Panel Mount | |
Pitch | 2.77mm | |
Mounting Hardware | Screw Holes | |
Series | AMPLIMITE | |
Select all | ||
---|---|---|
Brand TE Connectivity | ||
Number of Contacts 37 | ||
Gender Male | ||
Body Orientation Straight | ||
Mounting Type Panel Mount | ||
Pitch 2.77mm | ||
Mounting Hardware Screw Holes | ||
Series AMPLIMITE | ||
Non Compliant
- COO (Country of Origin):
- MX
The TE Connectivity Plug is designed to deliver robust connectivity solutions in panel mount applications, making it ideal for signal transmission in various electronic systems. It boasts an intricate design featuring 37 positions, allowing for versatile wiring configurations. Crafted from durable materials, including steel and cadmium plating, it combines resilience with functionality. The mating retention feature ensures secure connections, minimising the risk of disconnection during operation. This connector's ability to handle a maximum current rating of 7.5A further enhances its reliability, catering to demanding electrical requirements. With its compact centreline of 2.77 mm, this plug is suitable for space-constrained environments, ensuring effective use of available space. Utilising this connector enables greater efficiency and performance in cable-to-cable applications.
Panel mount design optimises installation in various equipment settings
37-position configuration allows for complex wiring needs
Constructed with high-quality materials to ensure longevity
Mating retention feature enhances connection stability
Crimp termination method allows for secure and reliable connections
Operating temperature range supports diverse environmental conditions
Compact form factor integrates seamlessly into smaller enclosures
37-position configuration allows for complex wiring needs
Constructed with high-quality materials to ensure longevity
Mating retention feature enhances connection stability
Crimp termination method allows for secure and reliable connections
Operating temperature range supports diverse environmental conditions
Compact form factor integrates seamlessly into smaller enclosures
