Wurth Elektronik 8 MHz Crystal ±20 ppm SMT 4-Pin 1.2 mm 7.2 mm 5.2mm
- RS Stock No.:
- 197-717
- Mfr. Part No.:
- 830059082
- Brand:
- Wurth Elektronik
Subtotal (1 reel of 1000 units)*
£691.00
(exc. VAT)
£829.00
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 08 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 1000 + | £0.691 | £691.00 |
*price indicative
- RS Stock No.:
- 197-717
- Mfr. Part No.:
- 830059082
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Standard Frequency | 8MHz | |
| Product Type | Crystal | |
| Mount Type | Surface Mount | |
| Load Capacitance | 10pF | |
| Package Type | SMT | |
| Packaging | Tape & Reel | |
| Pin Count | 4 | |
| Length | 7.2mm | |
| Width | 5.2mm | |
| Height | 1.2mm | |
| Frequency Tolerance | ±20 ppm | |
| Frequency Stability | ±50 ppm | |
| Minimum Operating Temperature | -20°C | |
| Series Resistance | 80Ω | |
| Maximum Operating Temperature | 70°C | |
| Series | 12SMX-B | |
| Standards/Approvals | RoHS, REACH | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Standard Frequency 8MHz | ||
Product Type Crystal | ||
Mount Type Surface Mount | ||
Load Capacitance 10pF | ||
Package Type SMT | ||
Packaging Tape & Reel | ||
Pin Count 4 | ||
Length 7.2mm | ||
Width 5.2mm | ||
Height 1.2mm | ||
Frequency Tolerance ±20 ppm | ||
Frequency Stability ±50 ppm | ||
Minimum Operating Temperature -20°C | ||
Series Resistance 80Ω | ||
Maximum Operating Temperature 70°C | ||
Series 12SMX-B | ||
Standards/Approvals RoHS, REACH | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik Quartz Crystal offers a standard 7 x 5mm SMD design that ensures optimal performance in various electronic applications. Crafted with precision, this hermetically sealed ceramic package features a robust metal lid, ensuring durability and reliability. Ideal for fundamental frequency applications at 8.0MHz, it meets stringent frequency tolerance and stability requirements, making it suitable for both consumer and industrial electronics. Compliance with RoHS standards showcases a commitment to eco friendly manufacturing, while the thoughtful design incorporates features that support easy integration into existing systems.
Operates within a broad temperature range for versatile applications
Ideal for high frequency electronics with low power consumption
Eco friendly materials comply with stringent RoHS standards
Easy integration into automated production lines with tape and reel packaging
Optimized for fundamental frequency applications for enhanced performance
