Wurth Elektronik 16 MHz Crystal ±30 ppm SMT 4-Pin 1.2 mm 7.2 mm 5.2 mm
- RS Stock No.:
- 197-728
- Mfr. Part No.:
- 830026392
- Brand:
- Wurth Elektronik
Subtotal (1 reel of 1000 units)*
£894.00
(exc. VAT)
£1,073.00
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit | Per Reel* |
|---|---|---|
| 1000 + | £0.894 | £894.00 |
*price indicative
- RS Stock No.:
- 197-728
- Mfr. Part No.:
- 830026392
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Product Type | Crystal | |
| Standard Frequency | 16MHz | |
| Mount Type | Surface Mount | |
| Load Capacitance | 16pF | |
| Package Type | SMT | |
| Packaging | Tape & Reel | |
| Pin Count | 4 | |
| Length | 7.2mm | |
| Width | 5.2 mm | |
| Height | 1.2mm | |
| Frequency Tolerance | ±30 ppm | |
| Frequency Stability | ±50 ppm | |
| Minimum Operating Temperature | -20°C | |
| Maximum Operating Temperature | 70°C | |
| Series Resistance | 40Ω | |
| Standards/Approvals | REACH, RoHS | |
| Series | 12SMX-B | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Product Type Crystal | ||
Standard Frequency 16MHz | ||
Mount Type Surface Mount | ||
Load Capacitance 16pF | ||
Package Type SMT | ||
Packaging Tape & Reel | ||
Pin Count 4 | ||
Length 7.2mm | ||
Width 5.2 mm | ||
Height 1.2mm | ||
Frequency Tolerance ±30 ppm | ||
Frequency Stability ±50 ppm | ||
Minimum Operating Temperature -20°C | ||
Maximum Operating Temperature 70°C | ||
Series Resistance 40Ω | ||
Standards/Approvals REACH, RoHS | ||
Series 12SMX-B | ||
Automotive Standard No | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik Standard 7 x 5mm SMD crystal is expertly designed for versatility and reliability in various electronic applications. Featuring a robust ceramic package with a hermetically sealed metal lid, this device not only ensures durability but also provides exceptional performance. Its fundamental overtone order guarantees precise frequency generation, making it suitable for high performance devices. With an impressive operating temperature range and compliance with strict RoHS regulations, this crystal supports environmentally friendly designs while facilitating optimal operational stability.
Utilizes a seamless metal LID for enhanced protection against environmental factors
Designed to comply with international standards for safe and effective use
Includes packaging in accordance with EIA 481 D for secure transport and handling
Supports a wide range of applications with its versatile specifications
Facilitates ease of integration into various electronic designs
