Belden 4504FE Control Cable, 6 Cores, 0.33 mm², Screened, 100m, Grey LSZH Sheath, 22 AWG
- RS Stock No.:
- 510-2303
- Mfr. Part No.:
- 4504FE.00100
- Brand:
- Belden
Subtotal (1 reel of 100 metres)*
£190.37
(exc. VAT)
£228.44
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1 unit(s) ready to ship
- Plus 3 unit(s) shipping from 14 November 2025
- Plus 2 unit(s) shipping from 05 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Reel(s) | Per Reel | Per Metre* |
|---|---|---|
| 1 + | £190.37 | £1.904 |
*price indicative
- RS Stock No.:
- 510-2303
- Mfr. Part No.:
- 4504FE.00100
- Brand:
- Belden
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Belden | |
| Series | 4504FE | |
| Number of Cores | 6 | |
| Cross Sectional Area | 0.33 mm² | |
| American Wire Gauge | 22 AWG | |
| Conductor Material | Copper | |
| Sheath Material | LSZH | |
| Sheath Colour | Grey | |
| Screened/Unscreened | Screened | |
| Screen Type | Aluminium/PET Foil | |
| Length | 100m | |
| Outer Diameter | 4.6mm | |
| Voltage Rating | 300 V | |
| CPR Certification | Eca | |
| Standards Met | Euroclass Eca | |
| Maximum Operating Temperature | +70°C | |
| Insulation Material | PE | |
| Drain Wire | Yes | |
| Cable Shape | Multicore | |
| Core Strands | 7/30 AWG | |
Select all | ||
|---|---|---|
Brand Belden | ||
Series 4504FE | ||
Number of Cores 6 | ||
Cross Sectional Area 0.33 mm² | ||
American Wire Gauge 22 AWG | ||
Conductor Material Copper | ||
Sheath Material LSZH | ||
Sheath Colour Grey | ||
Screened/Unscreened Screened | ||
Screen Type Aluminium/PET Foil | ||
Length 100m | ||
Outer Diameter 4.6mm | ||
Voltage Rating 300 V | ||
CPR Certification Eca | ||
Standards Met Euroclass Eca | ||
Maximum Operating Temperature +70°C | ||
Insulation Material PE | ||
Drain Wire Yes | ||
Cable Shape Multicore | ||
Core Strands 7/30 AWG | ||
- COO (Country of Origin):
- NL
Belden Control Cable, 100m Length, 6 Core - 4504FE.00100
Link sensors to your industrial equipment using this control cable from Belden. Its six cores are made of bare copper wire, which is highly conductive and supports reliable signal transmission. The conductors are colour-coded for ease of identification during installation. This cable has an aluminium and polyester shield that helps to reduce EMI, giving you noiseless signals. As it's supplied on a 100m reel, you'll have plenty in stock for use in multiple jobs.
Features & Benefits
• Wide operating temperature range of -20°C to +70°C for use in challenging environments
• LSZH sheath won't emit toxic fumes in the event of a fire
• LSZH sheath won't emit toxic fumes in the event of a fire
Applications
• Security and alarm systems
• Manufacturing machinery
• Intercom systems
• Manufacturing machinery
• Intercom systems
What's the voltage rating of this cable?
This cable has a voltage rating of 300V, so it's suitable for use in low-voltage applications.
