Lapp ÖLFLEX CLASSIC 110 YY Control Cable, 18 Cores, 0.75 mm², YY, Unscreened, 50m, Grey PVC Sheath, 18 AWG

RS Stock No.:: 445-4322
Mfr. Part No.:: 1119118
Brand:: Lapp

Lapp ÖLFLEX CLASSIC 110 YY Control Cable, 18 Cores, 0.75 mm², YY, Unscreened, 50m, Grey PVC Sheath, 18 AWG

50 In stock - FREE next working day delivery available

5 available from Europe for delivery within 2 working day(s).

Price 1 Reel of 50 Metre(s)

£245.19

(exc. VAT)

£294.23

(inc. VAT)

Reel(s)	Per Reel	Per Metre*
1 +	£245.19	£4.904

*price indicative

RS Stock No.:: 445-4322
Mfr. Part No.:: 1119118
Brand:: Lapp

Technical Reference

Legislation and Compliance

COO (Country of Origin):: DE

Product Details

LAPP Control Cable, 18AWG, 50m Length - ÖLFLEX CLASSIC 110 Series - 1119118

Use this robust cable from LAPP to connect sensors and actuators to control units in industrial systems. Thanks to its two unterminated ends, you have the freedom to choose a connector that suits your system's needs, making it a versatile choice. It's a YY cable, which means that both its insulation and outer sheath are made of PVC (polyvinyl chloride). This material provides impact and abrasion resistance for long-lasting performance as well as protection from electric shocks. You'll find cables like this one commonly used in manufacturing and automation applications.

Features & Benefits

• Copper conductor material for a reliable connection
• Wide operating temperature range of -40°C to +80°C for use in challenging environments
• Cores are twisted in layers to prevent electromagnetic interference (EMI) and ensure noiseless transmission
• Minimum bending radius of 15 times the cable diameter for maximum flexibility

Applications

• Machine tool engineering
• Bottling plants
• Automotive production lines

What's the length of this control cable?

The control cable comes in a length of 50 metres. This means there's enough for you to cut and either extend an existing connection or create a new one.

Standards

VDE 0295, Part 5

Specifications

Attribute	Value
Series	ÖLFLEX CLASSIC 110 YY
Number of Cores	18
Cross Sectional Area	0.75 mm²
Screened/Unscreened	Unscreened
Length	50m
Control Cable Type	YY
Sheath Colour	Grey
CPR Certification	Eca
American Wire Gauge	18 AWG
Outer Diameter	11.7mm
Sheath Material	PVC
Conductor Resistance	26 Ω/km
Voltage Rating	300/500 V
Current Rating	12 A
Filler Material	Non-Wicking Filler
Core Strands	24/0.2 mm
Minimum Bend Radius	Fixed - 4 x D Occasional flexing - 10 x D
Conductor Material	Copper
Earth Cable	Yes
Insulation Material	PVC
Minimum Operating Temperature	-40°C
Oil Resistant	Yes
Maximum Operating Temperature	+80°C
