Fluke A3004FC Clamp Meter, 99.9 mA 600 V dc CAT III Non-Contact Voltage Detector, UKAS
- RS Stock No.:
- 879-8758
- Mfr. Part No.:
- FLK-A3004FC
- Brand:
- Fluke
Subtotal (1 unit)*
£934.00
(exc. VAT)
£1,120.80
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 5 unit(s) ready to ship
- Plus 4 unit(s) shipping from 21 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £934.00 |
*price indicative
- RS Stock No.:
- 879-8758
- Mfr. Part No.:
- FLK-A3004FC
- Brand:
- Fluke
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Fluke | |
| Product Type | Clamp Meter | |
| Maximum DC Current Measurement | 99.9mA | |
| Maximum DC Voltage Measurement | 600V dc | |
| Model Number | A3004FC | |
| DC Voltage Resolution | 0.1 mV dc | |
| Maximum Jaw Opening | 4.5mm | |
| DC Current Resolution | 10μA | |
| DC Current Accuracy | 1 % | |
| Minimum Operating Temperature | -10°C | |
| AC Current Accuracy | 1.0 % + 3 | |
| DC Voltage Accuracy | 0.09 % + 2 | |
| Clamp Meter Type | DC Current Clamp Meter | |
| Maximum Operating Temperature | 50°C | |
| Weight | 299g | |
| Standards/Approvals | CE, CSA | |
| Width | 63.5mm | |
| Length | 14mm | |
| Height | 165mm | |
| Functions Measured | DC Current | |
| True RMS | Yes | |
| Battery Type | AA | |
| Display Type | LCD | |
| Non-Contact Voltage Detector | Yes | |
| Power Source | Battery | |
| Safety Category Voltage | 600V | |
| Calibrated | UKAS | |
| Safety Category Level | CAT III | |
| Battery Life | 45h | |
| Select all | ||
|---|---|---|
Brand Fluke | ||
Product Type Clamp Meter | ||
Maximum DC Current Measurement 99.9mA | ||
Maximum DC Voltage Measurement 600V dc | ||
Model Number A3004FC | ||
DC Voltage Resolution 0.1 mV dc | ||
Maximum Jaw Opening 4.5mm | ||
DC Current Resolution 10μA | ||
DC Current Accuracy 1 % | ||
Minimum Operating Temperature -10°C | ||
AC Current Accuracy 1.0 % + 3 | ||
DC Voltage Accuracy 0.09 % + 2 | ||
Clamp Meter Type DC Current Clamp Meter | ||
Maximum Operating Temperature 50°C | ||
Weight 299g | ||
Standards/Approvals CE, CSA | ||
Width 63.5mm | ||
Length 14mm | ||
Height 165mm | ||
Functions Measured DC Current | ||
True RMS Yes | ||
Battery Type AA | ||
Display Type LCD | ||
Non-Contact Voltage Detector Yes | ||
Power Source Battery | ||
Safety Category Voltage 600V | ||
Calibrated UKAS | ||
Safety Category Level CAT III | ||
Battery Life 45h | ||
RoHS Status: Exempt
- COO (Country of Origin):
- CN
Fluke Clamp Meter, 600V Safety Category Voltage, 4.5mm Maximum Jaw Opening - FLK-A3004FC
This clamp meter is a handheld instrument designed to measure DC current and voltage in industrial and field environments. It incorporates True RMS measurement and a non-contact voltage detector to support safe diagnostics on live circuits while operating within a 600V safety envelope and recognised CE and CSA approvals.
Features and Benefits:
• True RMS measurement delivers accurate readings for complex waveforms
• DC current accuracy ±0.2% rdg +5 digits ensures precise current assessment
• DC voltage resolution 0.1 mV enables fine voltage discrimination
• Maximum DC current measurement 99.9 mA supports low-current diagnostics
• Battery life 45h on AA cells provides extended field operation
• Safety category CAT III 600V protects measurements on building installations
• DC current accuracy ±0.2% rdg +5 digits ensures precise current assessment
• DC voltage resolution 0.1 mV enables fine voltage discrimination
• Maximum DC current measurement 99.9 mA supports low-current diagnostics
• Battery life 45h on AA cells provides extended field operation
• Safety category CAT III 600V protects measurements on building installations
Applications
• Suitable for pinpointing low-level DC faults in control systems
• Ideal for live voltage detection without direct contact
• Used with maintenance teams for electrical commissioning checks
• Can be used for troubleshooting sensors and small actuators
• Recommended for portable field testing and on-site inspections
• Ideal for live voltage detection without direct contact
• Used with maintenance teams for electrical commissioning checks
• Can be used for troubleshooting sensors and small actuators
• Recommended for portable field testing and on-site inspections
What display type assists in reading measurements outdoors?
The instrument uses an LCD to present numerical values and measurement modes clearly under varied lighting.
How compact is the jaw for accessing tight conductors?
The clamp jaw opens to 4.5mm allowing measurements on small-gauge conductors and confined cable bundles.
What power source and cell type does it require?
It operates from replaceable AA batteries, providing a typical run time of 45h under normal use.
Which temperature range supports operation on-site?
It functions between -10 °C and 50 °C for use across typical indoor and sheltered outdoor conditions.
