SKF E2.6312-2Z/C3 Single Row Deep Groove Ball Bearing- Both Sides Shielded 60mm I.D, 130mm O.D

View all Ball Bearings

Subtotal (1 unit)*

£71.69

(exc. VAT)

£86.03

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 1 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£71.69

*price indicative

Sponsored
image of tub of lubricator with blue and green sticker and white lid
SKF logo in blue reading SKF
SKF Single Point Lubricators
Maximize your bearing efficiency with SKF Lubricators. Improve efficiency, minimize downtime, and extend equipment life with our comprehensive guide.
Shop now
RS Stock No.:
797-5217
Mfr. Part No.:
E2.6312-2Z/C3
Brand:
SKF
Find similar products by selecting one or more attributes.
Select all

Brand

SKF

Inside Diameter

60mm

Outside Diameter

130mm

Race Width

31mm

Ball Bearing Type

Single Row Deep Groove Ball Bearing

Sealing Arrangement

Both Sides Shielded

Bearing Clearance

C3

Material

Steel

Ball Material

Steel

Cage Material

Non-metallic

Number of Rows

1

Static Load Rating

52kN

Dynamic Load Rating

81.9kN

Bore Type

Parallel

Bearing Series

3 Medium

Partial Bearing Code

6312

Race Type

Plain

RoHS Status: Exempt

COO (Country of Origin):
FR

SKF E2 Energy Efficient Bearings


SKF E2 Energy Efficient Bearings are deep-groove, shielded, ultra-low friction bearings that feature an optimised design, balanced between internal geometry, grease and cage type.

With 30 to 50% lower friction when compared with standard SKF bearings, the energy savings achievable when using SKF Energy Efficient Bearings are substantial, and the bearing life is extended significantly - in most cases more than double.

SKF E2 Energy Efficient Bearings offer ultra-low friction and typically generate less heat and can operate at higher speeds than ISO or SKF Explorer Bearings.

Dimensionally fully-compatible with standard bearings

Typical applications for SKF Energy Efficient Bearings include:

Electric motors up to 37kW (50HP)
Light to medium-loaded machines with shaft diameters up to 60mm
Excellent drop-in replacement for in-service electric motors
