SKF 6302-2RSH/C3 Single Row Deep Groove Ball Bearing- Both Sides Sealed 15mm I.D, 42mm O.D
- RS Stock No.:
- 667-1223
- Mfr. Part No.:
- 6302-2RSH/C3
- Brand:
- SKF
Bulk discount available
Subtotal (1 unit)*
£5.91
(exc. VAT)
£7.09
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 55 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £5.91 |
5 - 9 | £5.68 |
10 - 24 | £5.56 |
25 + | £5.42 |
*price indicative
- RS Stock No.:
- 667-1223
- Mfr. Part No.:
- 6302-2RSH/C3
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | SKF | |
Inside Diameter | 15mm | |
Outside Diameter | 42mm | |
Race Width | 13mm | |
Ball Bearing Type | Single Row Deep Groove Ball Bearing | |
Sealing Arrangement | Both Sides Sealed | |
Bearing Clearance | C3 | |
Material | Steel | |
Ball Material | Steel | |
Cage Material | Sheet Metal | |
Number of Rows | 1 | |
Static Load Rating | 5.4kN | |
Dynamic Load Rating | 11.9kN | |
Bore Type | Parallel | |
Bearing Series | 3 Medium | |
Partial Bearing Code | 6302 | |
Race Type | Plain | |
Model Number p | 63022RSC3 | |
Select all | ||
---|---|---|
Brand SKF | ||
Inside Diameter 15mm | ||
Outside Diameter 42mm | ||
Race Width 13mm | ||
Ball Bearing Type Single Row Deep Groove Ball Bearing | ||
Sealing Arrangement Both Sides Sealed | ||
Bearing Clearance C3 | ||
Material Steel | ||
Ball Material Steel | ||
Cage Material Sheet Metal | ||
Number of Rows 1 | ||
Static Load Rating 5.4kN | ||
Dynamic Load Rating 11.9kN | ||
Bore Type Parallel | ||
Bearing Series 3 Medium | ||
Partial Bearing Code 6302 | ||
Race Type Plain | ||
Model Number p 63022RSC3 | ||
RoHS Status: Exempt
- COO (Country of Origin):
- IT
SKF Ball Bearing, Deep-Groove Bearing Type, Single Row, 15mm ID, 42mm OD - 6302-2RSH/C3
Keep your rotating machinery running smoothly with this deep-groove ball bearing from SKF. It takes on combined radial and axial loads in both directions, so it's a handy workmate for multidirectional systems. The unit's sealed on both ends to prevent the lubricant from leaking out and dirt particles from getting in. Thanks to a basic dynamic load rating of 11.9kN and a static load rating of 5.4kN, this is a versatile component that handles heavy loads in moving and stationary applications without breaking a sweat.
Features & Benefits
• Built-in cage to keep the rolling parts stable and accurately spaced
• Limiting speed of 12,000r/min and reference speed of 38,000r/min safely handles high-speed rotation
• Synthetic rubber seals are resistant to oil and wear to withstand harsh environments
• Steel bearing housing resists corrosion
• Pre-lubricated for reduced maintenance
• Limiting speed of 12,000r/min and reference speed of 38,000r/min safely handles high-speed rotation
• Synthetic rubber seals are resistant to oil and wear to withstand harsh environments
• Steel bearing housing resists corrosion
• Pre-lubricated for reduced maintenance
Applications
• Manufacturing industry
• Construction equipment
• Metalworking facilities
• Robotics systems
• Industrial conveyors
• Construction equipment
• Metalworking facilities
• Robotics systems
• Industrial conveyors
Where should I use a sealed ball bearing?
As a sealed ball bearing is closed on both ends, dirt and moisture particles are securely locked out. This makes it ideal for situations where the risk of contamination is high and important to avoid.
