SKF 61800 Single Row Deep Groove Ball Bearing- Open Type 10mm I.D, 19mm O.D
- RS Stock No.:
- 286-7451
- Mfr. Part No.:
- 61800
- Brand:
- SKF
Bulk discount available
Subtotal (1 unit)*
£11.63
(exc. VAT)
£13.96
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 18 unit(s) ready to ship
- Plus 41 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £11.63 |
5 - 9 | £11.18 |
10 - 24 | £10.93 |
25 + | £10.71 |
*price indicative
- RS Stock No.:
- 286-7451
- Mfr. Part No.:
- 61800
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | SKF | |
Inside Diameter | 10mm | |
Outside Diameter | 19mm | |
Race Width | 5mm | |
Ball Bearing Type | Single Row Deep Groove Ball Bearing | |
Sealing Arrangement | Open Type | |
Bearing Clearance | CN | |
Material | Steel | |
Ball Material | Steel | |
Cage Material | Sheet Metal | |
Number of Rows | 1 | |
Static Load Rating | 830N | |
Dynamic Load Rating | 1.72kN | |
Bore Type | Parallel | |
Bearing Series | 1 Extra Light Thrust | |
Partial Bearing Code | 61800 | |
Race Type | Plain | |
Select all | ||
---|---|---|
Brand SKF | ||
Inside Diameter 10mm | ||
Outside Diameter 19mm | ||
Race Width 5mm | ||
Ball Bearing Type Single Row Deep Groove Ball Bearing | ||
Sealing Arrangement Open Type | ||
Bearing Clearance CN | ||
Material Steel | ||
Ball Material Steel | ||
Cage Material Sheet Metal | ||
Number of Rows 1 | ||
Static Load Rating 830N | ||
Dynamic Load Rating 1.72kN | ||
Bore Type Parallel | ||
Bearing Series 1 Extra Light Thrust | ||
Partial Bearing Code 61800 | ||
Race Type Plain | ||
RoHS Status: Exempt
- COO (Country of Origin):
- IT
SKF Deep-Groove Ball Bearing, 10mm ID, 19mm OD - 61800
Choose this deep-groove ball bearing from SKF to ensure the safe handling of radial and axial loads in your machinery. Its made of corrosion-resistant steel to ensure longevity in harsh industrial environments. The unit's plain raceway is optimised for low noise and minimal vibration and supports high rotational speeds of up to 4,800r/min (rotations per minute). Thanks to a high dynamic load rating of 1.38kN (kilonewtons) and a static load rating of 585N (newtons), this is a reliable choice for industrial applications.
• Open-ended design allows lubricant to move freely through the workings and makes relubrication easy
• Compact dimensions of 5 (W) x 10 (ID) x 19mm (OD) makes it suitable for installation in areas with limited space
• Low maintenance thanks to its durable steel ball bearings and smooth raceway
• Compact dimensions of 5 (W) x 10 (ID) x 19mm (OD) makes it suitable for installation in areas with limited space
• Low maintenance thanks to its durable steel ball bearings and smooth raceway
Applications
• Electric motors
• Household appliances
• Industrial automation
• Factory machinery
• Household appliances
• Industrial automation
• Factory machinery
How are different types of load defined?
Radial load is the maximum force moving in any direction that's applied perpendicular – or at a 90° angle to a machine's shaft. An axial load, on the other hand, is applied in the same direction at the shaft.
